Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CSBX1809-100MSMD HIGH CURRENT POWER INDUCTOR |
144 |
|
Datasheet |
CSBX1809 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 10 µH | ±20% | 16 A | 26A | Shielded | 6.9mOhm Max | - | - | AEC-Q200 | -55°C ~ 150°C | 100 kHz | High Saturation | Surface Mount | - | 0.760" L x 0.717" W (19.30mm x 18.20mm) | 0.362" (9.20mm) |
|
CSAB1770-560MSMD MOLDING POWER CHOKE |
140 |
|
Datasheet |
CSAB1770 | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 56 µH | ±20% | 6.5 A | 7A | Shielded | 58mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | Molded Inductors, Molding Power Choke | Surface Mount | 2-SMD | 0.701" L x 0.669" W (17.80mm x 17.00mm) | 0.283" (7.20mm) |
|
|
CSAB1770-6R8MSMD MOLDING POWER CHOKE |
140 |
|
Datasheet |
CSAB1770 | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 6.8 µH | ±20% | 17 A | 22A | Shielded | 7.55mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | Molded Inductors, Molding Power Choke | Surface Mount | 2-SMD | 0.701" L x 0.669" W (17.80mm x 17.00mm) | 0.283" (7.20mm) |
|
|
CSAB1770-8R2MSMD MOLDING POWER CHOKE |
140 |
|
Datasheet |
CSAB1770 | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 8.2 µH | ±20% | 16 A | 20A | Shielded | 8.7mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.701" L x 0.669" W (17.80mm x 17.00mm) | 0.283" (7.20mm) |
|
|
CSBX1809-2R7MSMD HIGH CURRENT POWER INDUCTOR |
138 |
|
Datasheet |
CSBX1809 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 2.7 µH | ±20% | 31.5 A | 50A | Shielded | 1.82mOhm Max | - | - | AEC-Q200 | -55°C ~ 150°C | 100 kHz | High Saturation | Surface Mount | - | 0.760" L x 0.717" W (19.30mm x 18.20mm) | 0.350" (8.90mm) |
|
|
CSBL1809-470MSMD HIGH CURRENT POWER INDUCTOR |
137 |
|
Datasheet |
CSBL1809 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 47 µH | ±20% | 6.8 A | 9.4A | Shielded | 38.8mOhm Max | - | - | AEC-Q200 | -50°C ~ 150°C | 100 kHz | Flat Wire, High Q Value | Surface Mount | - | 0.760" L x 0.717" W (19.30mm x 18.20mm) | 0.350" (8.90mm) |
|
CSBL1809-2R7MSMD HIGH CURRENT POWER INDUCTOR |
136 |
|
Datasheet |
CSBL1809 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 2.7 µH | ±20% | 31.5 A | 50A | Shielded | 1.82mOhm Max | - | - | AEC-Q200 | -50°C ~ 150°C | 100 kHz | Flat Wire, High Q Value | Surface Mount | - | 0.760" L x 0.717" W (19.30mm x 18.20mm) | 0.362" (9.20mm) |
|
|
CSBX1809-4R7MSMD HIGH CURRENT POWER INDUCTOR |
135 |
|
Datasheet |
CSBX1809 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 4.7 µH | ±20% | 22.5 A | 39A | Shielded | 3.4mOhm Max | - | - | AEC-Q200 | -55°C ~ 150°C | 100 kHz | High Saturation | Surface Mount | - | 0.760" L x 0.717" W (19.30mm x 18.20mm) | 0.362" (9.20mm) |
|
|
CSBX1809-5R6MSMD HIGH CURRENT POWER INDUCTOR |
132 |
|
Datasheet |
CSBX1809 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 5.6 µH | ±20% | 21 A | 35A | Shielded | 3.7mOhm Max | - | - | AEC-Q200 | -55°C ~ 150°C | 100 kHz | High Saturation | Surface Mount | - | 0.760" L x 0.717" W (19.30mm x 18.20mm) | 0.362" (9.20mm) |
|
|
CSBX1809-470MSMD HIGH CURRENT POWER INDUCTOR |
132 |
|
Datasheet |
CSBX1809 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 47 µH | ±20% | 6.8 A | 11.5A | Shielded | 38.8mOhm Max | - | - | AEC-Q200 | -55°C ~ 150°C | 100 kHz | High Saturation | Surface Mount | - | 0.760" L x 0.717" W (19.30mm x 18.20mm) | 0.350" (8.90mm) |
|
|
CSAB1770-470MSMD MOLDING POWER CHOKE |
130 |
|
Datasheet |
CSAB1770 | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 47 µH | ±20% | 7.1 A | 7.5A | Shielded | 47mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | Molded Inductors, Molding Power Choke | Surface Mount | 2-SMD | 0.701" L x 0.669" W (17.80mm x 17.00mm) | 0.283" (7.20mm) |
|
|
CSAB1770-220MSMD MOLDING POWER CHOKE |
125 |
|
Datasheet |
CSAB1770 | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 22 µH | ±20% | 9.5 A | 11A | Shielded | 23mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.701" L x 0.669" W (17.80mm x 17.00mm) | 0.283" (7.20mm) |
|
|
CSBL1809-2R0MSMD HIGH CURRENT POWER INDUCTOR |
125 |
|
Datasheet |
CSBL1809 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 2 µH | ±20% | 32.5 A | 57A | Shielded | 1.38mOhm Max | - | - | AEC-Q200 | -50°C ~ 150°C | 100 kHz | Flat Wire, High Q Value | Surface Mount | - | 0.760" L x 0.717" W (19.30mm x 18.20mm) | 0.350" (8.90mm) |
|
|
CSBL1809-150MSMD HIGH CURRENT POWER INDUCTOR |
116 |
|
Datasheet |
CSBL1809 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 15 µH | ±20% | 14 A | 19A | Shielded | 9.43mOhm Max | - | - | AEC-Q200 | -50°C ~ 150°C | 100 kHz | Flat Wire, High Q Value | Surface Mount | - | 0.760" L x 0.717" W (19.30mm x 18.20mm) | 0.362" (9.20mm) |
|
|
CSBL1809-220MSMD HIGH CURRENT POWER INDUCTOR |
114 |
|
Datasheet |
CSBL1809 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 22 µH | ±20% | 11 A | 14A | Shielded | 14.1mOhm Max | - | - | AEC-Q200 | -50°C ~ 150°C | 100 kHz | Flat Wire, High Q Value | Surface Mount | - | 0.760" L x 0.717" W (19.30mm x 18.20mm) | 0.362" (9.20mm) |
|
|
CSAB1770-R68MSMD MOLDING POWER CHOKE |
114 |
|
Datasheet |
CSAB1770 | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 0.7 µH | ±20% | 35 A | 57A | Shielded | 2mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | Molded Inductors, Molding Power Choke | Surface Mount | 2-SMD | 0.701" L x 0.669" W (17.80mm x 17.00mm) | 0.283" (7.20mm) |
|
|
CSBX1809-330MSMD HIGH CURRENT POWER INDUCTOR |
104 |
|
Datasheet |
CSBX1809 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 33 µH | ±20% | 8.5 A | 14A | Shielded | 23mOhm Max | - | - | AEC-Q200 | -55°C ~ 150°C | 100 kHz | High Saturation | Surface Mount | - | 0.760" L x 0.717" W (19.30mm x 18.20mm) | 0.362" (9.20mm) |
|
AFA41405B-70L70.0NH, 15%, 0.23MOHM, 145.0A MA |
700 |
|
Datasheet |
AFA41405B | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 70 nH | ±15% | 85 A | 145A | Unshielded | 0.23mOhm Max | - | - | - | -55°C ~ 130°C | 500 kHz | - | Surface Mount | - | 0.402" L x 0.189" W (10.20mm x 4.80mm) | 0.394" (10.00mm) |
|
|
AFA41405B-100L100.0nH, 15%, 0.23mOhm, 100.0A M |
200 |
|
Datasheet |
AFA41405B | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 100 nH | ±15% | 85 A | 100A | Unshielded | 0.23mOhm Max | - | - | - | -55°C ~ 130°C | 500 kHz | - | Surface Mount | - | 0.402" L x 0.189" W (10.20mm x 4.80mm) | 0.394" (10.00mm) |
|
|
CSBL1809-6R8MSMD HIGH CURRENT POWER INDUCTOR |
199 |
|
Datasheet |
CSBL1809 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Metal Composite | 6.8 µH | ±20% | 18.5 A | 31A | Shielded | 4.7mOhm Max | - | - | AEC-Q200 | -50°C ~ 150°C | 100 kHz | Flat Wire, High Q Value | Surface Mount | - | 0.760" L x 0.717" W (19.30mm x 18.20mm) | 0.362" (9.20mm) |
