Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MSS1048-103MLCFIXED IND 10UH 4.79A 23MOHM SM |
11,025 |
|
Datasheet |
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 10 µH | ±20% | 4.79 A | 3.08A | Shielded | 23mOhm Max | - | 24MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
MSS1048-104MLCFIXED IND 100UH 1.48A 224MOHM SM |
7,449 |
|
Datasheet |
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 100 µH | ±20% | 1.48 A | 990mA | Shielded | 224mOhm Max | - | 6MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
MSS1048-153MLCFIXED IND 15UH 4.26A 36MOHM SM |
6,358 |
|
Datasheet |
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 15 µH | ±20% | 4.26 A | 2.46A | Shielded | 36mOhm Max | - | 20MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
MSS1048-822NLCFIXED IND 8.2UH 5.71A 20MOHM SM |
5,847 |
|
Datasheet |
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 8.2 µH | ±30% | 5.71 A | 3.14A | Shielded | 20mOhm Max | - | 28MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
MSS1048-472NLCFIXED IND 4.7UH 6.9A 11.5MOHM SM |
5,515 |
|
Datasheet |
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 4.7 µH | ±30% | 6.9 A | 4.36A | Shielded | 11.5mOhm Max | - | 38MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
MSS1048-683MLCFIXED IND 68UH 1.88A 176MOHM SM |
5,364 |
|
Datasheet |
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 68 µH | ±20% | 1.88 A | 1.28A | Shielded | 176mOhm Max | - | 7MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
MSS1048-682NLCFIXED IND 6.8UH 6.01A 16.3MOHM |
4,983 |
|
Datasheet |
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 6.8 µH | ±30% | 6.01 A | 3.6A | Shielded | 16.3mOhm Max | - | 35MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
MSS1048-222NLCFIXED IND 2.2UH 9.78A 7.2MOHM SM |
3,466 |
|
Datasheet |
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 2.2 µH | ±30% | 9.78 A | 4.92A | Shielded | 7.2mOhm Max | - | 70MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
MSS1048-224KLCFIXED IND 220UH 1.18A 394MOHM SM |
3,428 |
|
Datasheet |
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 220 µH | ±10% | 1.18 A | 670mA | Shielded | 394mOhm Max | - | 4.5MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
XGL4040-332MECPOWER INDUCTOR, SHIELDED, COMPOS |
3,317 |
|
Datasheet |
XGL4040 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 3.3 µH | ±20% | 8.7 A | 5.5A | Shielded | 16.6mOhm Max | - | 32MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.161" (4.10mm) |
|
|
XGL4040-103MECPOWER INDUCTOR, SHIELDED, COMPOS |
3,301 |
|
Datasheet |
XGL4040 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 10 µH | ±20% | 5 A | 2.8A | Shielded | 50.5mOhm Max | - | 17MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.161" (4.10mm) |
|
|
MSS1048-333MLCFIXED IND 33UH 2.8A 68MOHM SM |
2,893 |
|
Datasheet |
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 33 µH | ±20% | 2.8 A | 1.66A | Shielded | 68mOhm Max | - | 11MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
MSS1048-154KLCFIXED IND 150UH 1.33A 330MOHM SM |
2,690 |
|
Datasheet |
MSS1048 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 150 µH | ±10% | 1.33 A | 790mA | Shielded | 330mOhm Max | - | 5MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.402" L x 0.394" W (10.20mm x 10.00mm) | 0.201" (5.10mm) |
|
|
XGL4040-471MECPOWER INDUCTOR, SHIELDED, COMPOS |
2,461 |
|
Datasheet |
XGL4040 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 470 nH | ±20% | 20.8 A | 12.2A | Shielded | 3.2mOhm Max | - | 90MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.161" (4.10mm) |
|
|
XGL4040-301MECPOWER INDUCTOR, SHIELDED, COMPOS |
2,414 |
|
Datasheet |
XGL4040 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 300 nH | ±20% | 24.6 A | 15.3A | Shielded | 2.6mOhm Max | - | 120MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.161" (4.10mm) |
|
|
XGL4040-153MECPOWER INDUCTOR, SHIELDED, COMPOS |
2,366 |
|
Datasheet |
XGL4040 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 15 µH | ±20% | 3.6 A | 2.5A | Shielded | 82.2mOhm Max | - | 12MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.161" (4.10mm) |
|
|
XGL4040-822MECPOWER INDUCTOR, SHIELDED, COMPOS |
2,135 |
|
Datasheet |
XGL4040 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 8.2 µH | ±20% | 5.4 A | 3.3A | Shielded | 41.2mOhm Max | - | 18MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.161" (4.10mm) |
|
|
XGL4040-151MECPOWER INDUCTOR, SHIELDED, COMPOS |
2,123 |
|
Datasheet |
XGL4040 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 150 nH | ±20% | 22.3 A | 21A | Shielded | 1.8mOhm Max | - | 190MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.161" (4.10mm) |
|
|
XGL4040-102MECPOWER INDUCTOR, SHIELDED, COMPOS |
2,066 |
|
Datasheet |
XGL4040 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 1 µH | ±20% | 14.8 A | 9.3A | Shielded | 5.6mOhm Max | - | 55MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.161" (4.10mm) |
|
|
XGL4040-152MECPOWER INDUCTOR, SHIELDED, COMPOS |
2,032 |
|
Datasheet |
XGL4040 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 1.5 µH | ±20% | 12.5 A | 7.9A | Shielded | 7.9mOhm Max | - | 47MHz | AEC-Q200 | -40°C ~ 165°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.161" (4.10mm) |
