Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
12RS104CFIXED IND 100UH 1.4A 190 MOHM TH |
459 |
|
Datasheet |
1200RS | Radial, Vertical Cylinder, 4 Leads | Bulk | Active | Wirewound | - | 100 µH | ±15% | 1.4 A | - | Shielded | 190mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.413" Dia (10.50mm) | 0.335" (8.50mm) |
|
HCM1A0703V2-4R7-RFIXED IND 4.7UH 4A 46.5 MOHM SMD |
325 |
|
Datasheet |
HCM1AV2 | Nonstandard | Tape & Reel (TR) | Active | - | Iron Powder | 4.7 µH | ±20% | 4 A | 6.8A | Shielded | 46.5mOhm Max | - | 20MHz | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.276" L x 0.260" W (7.00mm x 6.60mm) | 0.118" (3.00mm) |
|
7447462220FIXED IND 22UH 1.8A 130 MOHM TH |
306 |
|
Datasheet |
WE-TI | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | 22 µH | ±20% | 1.8 A | 1.7A | Unshielded | 130mOhm Max | - | 15MHz | - | -40°C ~ 125°C | 1 kHz | - | Through Hole | - | 0.236" Dia (6.00mm) | 0.335" (8.50mm) |
|
|
7447462100FIXED IND 10UH 2.5A 80 MOHM TH |
303 |
|
Datasheet |
WE-TI | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | 10 µH | ±20% | 2.5 A | 2.6A | Unshielded | 80mOhm Max | - | 28MHz | - | -40°C ~ 125°C | 1 kHz | - | Through Hole | - | 0.236" Dia (6.00mm) | 0.335" (8.50mm) |
|
|
7447462470FIXED IND 47UH 1.18A 340 MOHM TH |
293 |
|
Datasheet |
WE-TI | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | 47 µH | ±20% | 1.18 A | 1.2A | Unshielded | 340mOhm Max | - | 10.6MHz | - | -40°C ~ 125°C | 1 kHz | - | Through Hole | - | 0.236" Dia (6.00mm) | 0.335" (8.50mm) |
|
|
12RS683CFIXED IND 68UH 1.8A 150 MOHM TH |
251 |
|
Datasheet |
1200RS | Radial, Vertical Cylinder, 4 Leads | Bulk | Active | Wirewound | - | 68 µH | ±15% | 1.8 A | - | Shielded | 150mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.413" Dia (10.50mm) | 0.335" (8.50mm) |
|
|
12RS333CFIXED IND 33UH 2.7A 57 MOHM TH |
246 |
|
Datasheet |
1200RS | Radial, Vertical Cylinder, 4 Leads | Bulk | Active | Wirewound | - | 33 µH | ±15% | 2.7 A | - | Shielded | 57mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.413" Dia (10.50mm) | 0.335" (8.50mm) |
|
|
7447462033FIXED IND 3.3UH 4.7A 25 MOHM TH |
220 |
|
Datasheet |
WE-TI | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | 3.3 µH | ±20% | 4.7 A | 4A | Unshielded | 25mOhm Max | - | 48MHz | - | -40°C ~ 125°C | 1 kHz | - | Through Hole | - | 0.236" Dia (6.00mm) | 0.335" (8.50mm) |
|
|
7447462101FIXED IND 100UH 800MA 550MOHM TH |
172 |
|
Datasheet |
WE-TI | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | 100 µH | ±10% | 800 mA | 800mA | Unshielded | 550mOhm Max | - | 7.1MHz | - | -40°C ~ 125°C | 1 kHz | - | Through Hole | - | 0.236" Dia (6.00mm) | 0.335" (8.50mm) |
|
|
12RS224CFIXED IND 220UH 1.1A 290 MOHM TH |
1,851 |
|
Datasheet |
1200RS | Radial, Vertical Cylinder, 4 Leads | Bulk | Active | Wirewound | - | 220 µH | ±15% | 1.1 A | - | Shielded | 290mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.413" Dia (10.50mm) | 0.335" (8.50mm) |
|
|
7447462330FIXED IND 33UH 1.4A 220 MOHM TH |
2,776 |
|
Datasheet |
WE-TI | Radial, Vertical Cylinder | Bulk | Active | Drum Core, Wirewound | Ferrite | 33 µH | ±20% | 1.4 A | 1.4A | Unshielded | 220mOhm Max | - | 14MHz | - | -40°C ~ 125°C | 1 kHz | - | Through Hole | - | 0.236" Dia (6.00mm) | 0.335" (8.50mm) |
|
SRU6013-1R5YFIXED IND 1.5UH 3A 40 MOHM SMD |
1,770 |
|
Datasheet |
SRU6013 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 1.5 µH | ±30% | 3 A | 2.4A | Shielded | 40mOhm Max | 10 @ 7.96MHz | 90MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.256" L x 0.244" W (6.50mm x 6.20mm) | 0.063" (1.60mm) |
|
SRR0604-6R8MLFIXED IND 6.8UH 1.6A 70 MOHM SMD |
1,565 |
|
Datasheet |
SRR0604 | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 6.8 µH | ±20% | 1.6 A | 2.05A | Shielded | 70mOhm Max | 20 @ 7.96MHz | 37MHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.256" L x 0.256" W (6.50mm x 6.50mm) | 0.189" (4.80mm) |
|
|
SRR0604-221KLFIXED IND 220UH 250MA 1.7OHM SMD |
1,178 |
|
Datasheet |
SRR0604 | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 220 µH | ±10% | 250 mA | 320mA | Shielded | 1.7Ohm Max | 20 @ 796kHz | 10MHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.256" L x 0.256" W (6.50mm x 6.50mm) | 0.189" (4.80mm) |
|
SLF6028T-680MR50-PFFIXED IND 68UH 780MA 348MOHM SMD |
1,000 |
|
Datasheet |
SLF | Nonstandard | Tape & Reel (TR) | Last Time Buy | Drum Core, Wirewound | Ferrite | 68 µH | ±20% | 780 mA | 500mA | Shielded | 348mOhm Max | - | - | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.236" W (6.00mm x 6.00mm) | 0.118" (3.00mm) |
|
SRR0603-330KLFIXED IND 33UH 600MA 430MOHM SMD |
964 |
|
Datasheet |
SRR0603 | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 33 µH | ±10% | 600 mA | 830mA | Shielded | 430mOhm Max | 15 @ 2.52MHz | 16MHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.256" L x 0.256" W (6.50mm x 6.50mm) | 0.130" (3.30mm) |
|
|
SRR0604-222KLFIXED IND 2.2MH 100MA 16 OHM SMD |
910 |
|
Datasheet |
SRR0604 | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 2.2 mH | ±10% | 100 mA | 80mA | Shielded | 16Ohm Max | 80 @ 252kHz | 650kHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.256" L x 0.256" W (6.50mm x 6.50mm) | 0.189" (4.80mm) |
|
|
SRR0604-471KLFIXED IND 470UH 180MA 3.3OHM SMD |
834 |
|
Datasheet |
SRR0604 | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 470 µH | ±10% | 180 mA | 220mA | Shielded | 3.3Ohm Max | 18 @ 796kHz | 6.5MHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.256" L x 0.256" W (6.50mm x 6.50mm) | 0.189" (4.80mm) |
|
|
SRR0603-221KLFIXED IND 220UH 200MA 2.7OHM SMD |
815 |
|
Datasheet |
SRR0603 | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 220 µH | ±10% | 200 mA | 310mA | Shielded | 2.7Ohm Max | 20 @ 796kHz | 5MHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.256" L x 0.256" W (6.50mm x 6.50mm) | 0.130" (3.30mm) |
|
|
SRR0604-680KLFIXED IND 68UH 500MA 520MOHM SMD |
720 |
|
Datasheet |
SRR0604 | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 68 µH | ±10% | 500 mA | 680mA | Shielded | 520mOhm Max | 15 @ 2.52MHz | 15MHz | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.256" L x 0.256" W (6.50mm x 6.50mm) | 0.189" (4.80mm) |
