Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PM4548.472NLTFIXED IND 4.7UH 5.5A 50 MOHM SMD |
367 |
|
Datasheet |
PM4548.XXXNLT | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 4.7 µH | ±20% | 5.5 A | 9A | Unshielded | 50mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.299" L x 0.272" W (7.60mm x 6.90mm) | 0.118" (3.00mm) |
|
SPRH124-101MSMD POWER INDUCTOR |
3,000 |
|
Datasheet |
SPRH124 | 2-SMD | Cut Tape (CT) | Active | Drum Core, Wirewound | Ferrite | 100 µH | ±20% | 1.46 A | 1.99A | Shielded | 272mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | Drum Core, Power Inductor | Surface Mount | 2-SMD | 0.472" L x 0.472" W (12.00mm x 12.00mm) | 0.181" (4.60mm) |
|
MPL-AY3020-6R8FIXED IND 6.8UH 1.65A 250MOHM SM |
2,990 |
|
- |
MPL-AY | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Molded | - | 6.8 µH | - | 1.65 A | 2.6A | Unshielded | 250mOhm | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.138" L x 0.126" W (3.50mm x 3.20mm) | 0.079" (2.00mm) |
|
|
MPL-AY3020-5R6FIXED IND 5.6UH 1.8A 209MOHM SMD |
2,837 |
|
- |
MPL-AY | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Molded | - | 5.6 µH | - | 1.8 A | 2.8A | Unshielded | 209mOhm | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.138" L x 0.126" W (3.50mm x 3.20mm) | 0.079" (2.00mm) |
|
|
MPL-AY3020-R82FIXED IND 820NH 4.7A 28 MOHM SMD |
2,818 |
|
- |
MPL-AY | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Molded | - | 820 nH | - | 4.7 A | 8A | Unshielded | 28mOhm | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.138" L x 0.126" W (3.50mm x 3.20mm) | 0.079" (2.00mm) |
|
|
MPL-AY3020-R47FIXED IND 470NH 6.3A 19.5MOHM SM |
2,803 |
|
- |
MPL-AY | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Molded | - | 470 nH | - | 6.3 A | 9A | Unshielded | 19.5mOhm | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.138" L x 0.126" W (3.50mm x 3.20mm) | 0.079" (2.00mm) |
|
SRP5020C-3R3MFIXED IND 3.3UH 4A 74 MOHM SMD |
2,391 |
|
Datasheet |
SRP5020C | Nonstandard | Tape & Reel (TR) | Obsolete | - | Metal | 3.3 µH | ±20% | 4 A | 7A | Shielded | 74mOhm Max | 20 @ 100kHz | 30MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.224" L x 0.205" W (5.70mm x 5.20mm) | 0.079" (2.00mm) |
|
|
MPL-AY3020-100FIXED IND 10UH 1.3A 370 MOHM SMD |
2,088 |
|
- |
MPL-AY | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Molded | - | 10 µH | - | 1.3 A | 1.75A | Unshielded | 370mOhm | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.138" L x 0.126" W (3.50mm x 3.20mm) | 0.079" (2.00mm) |
|
|
TMPF 0403LR-3R3MN-ABD3.3 UH SHIELDED MOLDED INDUCTOR |
1,613 |
|
Datasheet |
TMPF0403LR-ABD | Nonstandard | Cut Tape (CT) | Active | Molded | - | 3.3 µH | ±20% | 5 A | 6.2A | Unshielded | 28.6mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 0.118" (3.00mm) |
|
VLF252015MT-1R5N-CAFIXED IND 1.5UH 2.58A 39MOHM SMD |
1,594 |
|
Datasheet |
VLF-M-CA | 1008 (2520 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 1.5 µH | ±30% | 2.58 A | 1.13A | Shielded | 39mOhm Max | - | - | - | -40°C ~ 105°C | 1 MHz | - | Surface Mount | - | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.059" (1.50mm) |
|
|
TMPF 0403LR-1R0MN-ABD1.0 UH SHIELDED MOLDED INDUCTOR |
1,577 |
|
Datasheet |
TMPF0403LR-ABD | Nonstandard | Cut Tape (CT) | Active | Molded | - | 1 µH | ±20% | 8 A | 9.8A | Unshielded | 10.1mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 0.118" (3.00mm) |
|
SRP7028C-150MFIXED IND 15UH 3A 123 MOHM SMD |
985 |
|
Datasheet |
SRP7028C | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Metal | 15 µH | ±20% | 3 A | 4A | Shielded | 123mOhm Max | 20 @ 100kHz | 12MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.280" L x 0.260" W (7.10mm x 6.60mm) | 0.118" (3.00mm) |
|
CLF7045T-3R3N-HFIXED IND 3.3UH 5A 16.4 MOHM SMD |
757 |
|
Datasheet |
CLF-H | Nonstandard | Tape & Reel (TR) | Last Time Buy | Drum Core, Wirewound | Ferrite | 3.3 µH | ±30% | 5 A | 4.1A | Shielded | 16.4mOhm | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.283" L x 0.272" W (7.20mm x 6.90mm) | 0.177" (4.50mm) |
|
|
SRP7028C-3R3MFIXED IND 3.3UH 6A 30 MOHM SMD |
583 |
|
Datasheet |
SRP7028C | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Metal | 3.3 µH | ±20% | 6 A | 13.5A | Shielded | 30mOhm Max | 15 @ 100kHz | 25MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.280" L x 0.260" W (7.10mm x 6.60mm) | 0.118" (3.00mm) |
|
|
MPL-AY3020-8R2FIXED IND 8.2UH 1.4A 345MOHM SMD |
539 |
|
- |
MPL-AY | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Molded | - | 8.2 µH | - | 1.4 A | 1.95A | Unshielded | 345mOhm | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.138" L x 0.126" W (3.50mm x 3.20mm) | 0.079" (2.00mm) |
|
|
SRP7028C-2R2MFIXED IND 2.2UH 8A 18 MOHM SMD |
151 |
|
Datasheet |
SRP7028C | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Metal | 2.2 µH | ±20% | 8 A | 14A | Shielded | 18mOhm Max | 15 @ 100kHz | 32MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.280" L x 0.260" W (7.10mm x 6.60mm) | 0.118" (3.00mm) |
|
|
SRP7028C-6R8MFIXED IND 6.8UH 4.5A 60MOHM SMD |
108 |
|
Datasheet |
SRP7028C | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Metal | 6.8 µH | ±20% | 4.5 A | 8.3A | Shielded | 60mOhm Max | 15 @ 100kHz | 16MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.280" L x 0.260" W (7.10mm x 6.60mm) | 0.118" (3.00mm) |
|
|
0805CS-121XJRCFIXED IND 120NH 400MA 510MOHM SM |
103,566 |
|
Datasheet |
0805CS | 0805 (2012 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 120 nH | ±5% | 400 mA | - | Unshielded | 510mOhm Max | 50 @ 250MHz | 1.1GHz | AEC-Q200 | -40°C ~ 125°C | 150 MHz | - | Surface Mount | 0805 | 0.090" L x 0.068" W (2.29mm x 1.73mm) | 0.060" (1.52mm) |
|
|
0603CS-R18XJRWFIXED IND 180NH 240MA 1.25OHM SM |
86,707 |
|
Datasheet |
0603CS | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 180 nH | ±5% | 240 mA | - | Unshielded | 1.25Ohm Max | 25 @ 100MHz | 990MHz | AEC-Q200 | -40°C ~ 125°C | 100 MHz | - | Surface Mount | 0603 | 0.071" L x 0.044" W (1.80mm x 1.12mm) | 0.040" (1.02mm) |
|
|
0603CS-R39XJRWFIXED IND 390NH 100MA 4.35OHM SM |
79,688 |
|
Datasheet |
0603CS | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 390 nH | ±5% | 100 mA | - | Unshielded | 4.35Ohm Max | 25 @ 100MHz | 780MHz | AEC-Q200 | -40°C ~ 125°C | 100 MHz | - | Surface Mount | 0603 | 0.071" L x 0.044" W (1.80mm x 1.12mm) | 0.040" (1.02mm) |
