Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MLP22-824LMOLDED AXL UNSHIELDED INDUCTOR |
4,076 |
|
Datasheet |
MLP22 | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 8.2 mH | ±15% | 77 mA | 77mA | Unshielded | 66Ohm Max | - | - | - | -55°C ~ 130°C | 1 kHz | - | Through Hole | Axial | 0.215" Dia x 0.560" L (5.46mm x 14.22mm) | - |
|
|
MLP22-104LMOLDED AXL UNSHIELDED INDUCTOR |
3,404 |
|
Datasheet |
MLP22 | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 1 mH | ±15% | 240 mA | 240mA | Unshielded | 6.9Ohm Max | - | - | - | -55°C ~ 130°C | 1 kHz | - | Through Hole | Axial | 0.215" Dia x 0.560" L (5.46mm x 14.22mm) | - |
|
|
MLP22-274LMOLDED AXL UNSHIELDED INDUCTOR |
3,792 |
|
Datasheet |
MLP22 | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 2.7 mH | ±15% | 131 mA | 131mA | Unshielded | 23Ohm Max | - | - | - | -55°C ~ 130°C | 1 kHz | - | Through Hole | Axial | 0.215" Dia x 0.560" L (5.46mm x 14.22mm) | - |
|
|
MLP22-125LMOLDED AXL UNSHIELDED INDUCTOR |
3,748 |
|
Datasheet |
MLP22 | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 12 mH | ±15% | 65 mA | 65mA | Unshielded | 93Ohm Max | - | - | - | -55°C ~ 130°C | 1 kHz | - | Through Hole | Axial | 0.215" Dia x 0.560" L (5.46mm x 14.22mm) | - |
|
|
MLP22-564LMOLDED AXL UNSHIELDED INDUCTOR |
2,365 |
|
Datasheet |
MLP22 | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 5.6 mH | ±15% | 100 mA | 100mA | Unshielded | 40Ohm Max | - | - | - | -55°C ~ 130°C | 1 kHz | - | Through Hole | Axial | 0.215" Dia x 0.560" L (5.46mm x 14.22mm) | - |
|
|
MLP22-184LMOLDED AXL UNSHIELDED INDUCTOR |
3,581 |
|
Datasheet |
MLP22 | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 1.8 mH | ±15% | 157 mA | 157mA | Unshielded | 16Ohm Max | - | - | - | -55°C ~ 130°C | 1 kHz | - | Through Hole | Axial | 0.215" Dia x 0.560" L (5.46mm x 14.22mm) | - |
|
|
MLP22-155LMOLDED AXL UNSHIELDED INDUCTOR |
1,811 |
|
Datasheet |
MLP22 | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 15 mH | ±15% | 61 mA | 61mA | Unshielded | 105Ohm Max | - | - | - | -55°C ~ 130°C | 1 kHz | - | Through Hole | Axial | 0.215" Dia x 0.560" L (5.46mm x 14.22mm) | - |
|
|
CC4H1008-018GCERAMIC SMT CHIP INDUCTOR |
1,311 |
|
Datasheet |
CC4H1008 | 1008 (2520 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 18 nH | ±2% | 1.6 A | - | Unshielded | 110mOhm | 65 @ 350MHz | 2.6GHz | - | -55°C ~ 125°C | 50 MHz | - | Surface Mount | 1008 | 0.120" L x 0.110" W (3.05mm x 2.79mm) | 0.090" (2.29mm) |
|
|
CC4H1008-010GCERAMIC SMT CHIP INDUCTOR |
4,122 |
|
Datasheet |
CC4H1008 | 1008 (2520 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 10 nH | ±2% | 1.84 A | - | Unshielded | 90mOhm | 50 @ 500MHz | 3.1GHz | - | -55°C ~ 125°C | 50 MHz | - | Surface Mount | 1008 | 0.120" L x 0.110" W (3.05mm x 2.79mm) | 0.090" (2.29mm) |
|
HC8-R15-RFIXED IND 150NH 39A 0.8 MOHM SMD |
3,677 |
|
Datasheet |
HC8 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Iron Powder | 150 nH | ±20% | 39 A | 76A | Unshielded | 0.8mOhm Max | - | - | - | -40°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.429" L x 0.409" W (10.90mm x 10.40mm) | 0.157" (4.00mm) |
|
PL9515TFIXED IND 47UH 600MA 230MOHM SMD |
1,022 |
|
Datasheet |
PL95XX | Nonstandard | Tape & Reel (TR) | Active | - | - | 47 µH | ±20% | 600 mA | 600mA | Shielded | 230mOhm Max | - | - | - | -55°C ~ 130°C | - | - | Surface Mount | - | 0.256" L x 0.256" W (6.50mm x 6.50mm) | 0.122" (3.10mm) |
|
|
CLA1108-2-50TR-RFIXED IND 50NH 80A 0.00028OHM SM |
1,080 |
|
Datasheet |
CLA | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 50 nH | ±20% | 80 A | - | - | 0.28mOhm | - | - | - | -40°C ~ 125°C | 1 MHz | 2 Phase | Surface Mount | - | 0.709" L x 0.433" W (18.00mm x 11.00mm) | 0.315" (8.00mm) |
|
|
SMRF5025S-821KMOLDED SHIELDED INDUCTOR |
1,336 |
|
Datasheet |
SMRF5025S | Nonstandard | Tape & Reel (TR) | Active | Molded | Iron Powder | 8.2 µH | ±10% | 535 mA | 535mA | Shielded | 1.32Ohm Max | 40 @ 7.9MHz | 43MHz | - | -55°C ~ 125°C | 7.9 MHz | - | Surface Mount | - | 0.500" L x 0.240" W (12.70mm x 6.10mm) | 0.230" (5.84mm) |
|
SWC-2.70-77FIXED IND 77UH 2.7A 90 MOHM TH |
2,437 |
|
Datasheet |
SW | Radial, Vertical (Open) | Bulk | Obsolete | Toroidal | Iron Powder | 77 µH | ±20% | 2.7 A | - | Unshielded | 90mOhm | - | - | - | -40°C ~ 125°C | 10 kHz | - | Through Hole | - | 0.827" L x 0.449" W (21.00mm x 11.40mm) | 0.937" (23.80mm) |
|
|
SH150C-2.70-77FIXED IND 77UH 2.7A 90 MOHM TH |
3,179 |
|
Datasheet |
SH150 | Radial, Vertical (Open) | Tray | Active | Toroidal | Iron Powder | 77 µH | ±20% | 2.7 A | - | Unshielded | 90mOhm | - | - | - | -40°C ~ 125°C | 10 kHz | - | Through Hole | - | 0.827" L x 0.449" W (21.00mm x 11.40mm) | 0.937" (23.80mm) |
|
S34547FIXED IND 150UH 180 MOHM TH |
3,583 |
|
Datasheet |
- | Radial, Horizontal, 8 Leads | Bulk | Active | - | - | 150 µH | - | - | - | Unshielded | 180mOhm Max | - | 950kHz | - | -45°C ~ 250°C | 10 kHz | - | Through Hole | - | 0.500" L x 0.470" W (12.70mm x 11.94mm) | 0.450" (11.43mm) |
|
|
DB1-471RADIAL POWR LINE CHOKE |
3,378 |
|
Datasheet |
DB1 | Radial, Vertical Cylinder (Open) | Bulk | Active | Wirewound | Ferrite | 4.7 µH | ±20% | 9 A | 32A | Unshielded | 7mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 0.650" Dia (16.51mm) | 0.712" (18.08mm) |
|
|
MIL8532-26LFIXED IND 120UH 1.12A 283MOHM SM |
1,144 |
|
Datasheet |
MIL8532 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 120 µH | ±15% | 1.12 A | 580mA | Unshielded | 283mOhm Max | - | - | - | -55°C ~ 130°C | 1 kHz | - | Surface Mount | - | 0.880" L x 0.330" W (22.35mm x 8.38mm) | 0.286" (7.26mm) |
|
|
MIL8532-27LFIXED IND 150UH 1.04A 330MOHM SM |
2,584 |
|
Datasheet |
MIL8532 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 150 µH | ±15% | 1.04 A | 520mA | Unshielded | 330mOhm Max | - | - | - | -55°C ~ 130°C | 1 kHz | - | Surface Mount | - | 0.880" L x 0.330" W (22.35mm x 8.38mm) | 0.286" (7.26mm) |
|
|
MIL8532-28LFIXED IND 180UH 990MA 362MOHM SM |
4,488 |
|
Datasheet |
MIL8532 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 180 µH | ±15% | 990 mA | 480mA | Unshielded | 362mOhm Max | - | - | - | -55°C ~ 130°C | 1 kHz | - | Surface Mount | - | 0.880" L x 0.330" W (22.35mm x 8.38mm) | 0.286" (7.26mm) |
