Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MLP22-391LMOLDED AXL UNSHIELDED INDUCTOR |
1,091 |
|
Datasheet |
MLP22 | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 3.9 µH | ±15% | 3.07 A | 3.07A | Unshielded | 42mOhm Max | - | - | - | -55°C ~ 130°C | 1 kHz | - | Through Hole | Axial | 0.215" Dia x 0.560" L (5.46mm x 14.22mm) | - |
|
|
MLP22-681LMOLDED AXL UNSHIELDED INDUCTOR |
4,675 |
|
Datasheet |
MLP22 | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 6.8 µH | ±15% | 2.61 A | 2.61A | Unshielded | 58mOhm Max | - | - | - | -55°C ~ 130°C | 1 kHz | - | Through Hole | Axial | 0.215" Dia x 0.560" L (5.46mm x 14.22mm) | - |
|
SWS-5.0-15FIXED IND 15UH 5A 27 MOHM SMD |
3,103 |
|
Datasheet |
SW | Nonstandard | Tape & Reel (TR) | Obsolete | Toroidal | Iron Powder | 15 µH | ±20% | 5 A | - | Unshielded | 27mOhm | - | - | - | -40°C ~ 130°C | 10 kHz | - | Surface Mount | - | 0.701" L x 0.669" W (17.80mm x 17.00mm) | 0.400" (10.16mm) |
|
|
SH260S-5.0-15FIXED IND 15UH 5A 27 MOHM SMD |
4,492 |
|
Datasheet |
SH260 | Nonstandard | Tape & Reel (TR) | Active | Toroidal | Iron Powder | 15 µH | ±20% | 5 A | - | Unshielded | 27mOhm | - | - | - | -40°C ~ 125°C | 10 kHz | - | Surface Mount | - | 0.701" L x 0.669" W (17.80mm x 17.00mm) | 0.451" (11.45mm) |
|
LGJ7045TC-101M-HFIXED IND 100UH 750MA 330MOHM SM |
3,583 |
|
Datasheet |
LGJ | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 100 µH | ±20% | 750 mA | 900mA | Shielded | 330mOhm | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.283" L x 0.272" W (7.20mm x 6.90mm) | 0.177" (4.50mm) |
|
CSBX1275-100MSMD HIGH CURRENT POWER INDUCTOR |
4,149 |
|
Datasheet |
CSBX1275 | Nonstandard | Active | Wirewound | Metal Composite | 10 µH | ±20% | 11 A | 21A | Shielded | 10.1mOhm Max | - | - | AEC-Q200 | -55°C ~ 150°C | 100 kHz | High Saturation | Surface Mount | - | 0.543" L x 0.504" W (13.80mm x 12.80mm) | 0.299" (7.60mm) | |
|
|
CSBL1265-150MSMD HIGH CURRENT POWER INDUCTOR |
2,271 |
|
Datasheet |
CSBL1265 | Nonstandard | Active | Wirewound | Metal Composite | 15 µH | ±20% | 9 A | 9.5A | Shielded | 14.1mOhm Max | - | - | AEC-Q200 | -50°C ~ 150°C | 100 kHz | Flat Wire, High Q Value | Surface Mount | - | 0.543" L x 0.504" W (13.80mm x 12.80mm) | 0.244" (6.20mm) | |
|
|
CC0805-150GSCERAMIC SMT CHIP INDUCTOR |
1,909 |
|
Datasheet |
CC0805 | Nonstandard | Tape & Reel (TR) | Active | - | Ceramic | 150 nH | ±2% | 400 mA | - | Unshielded | 700mOhm Max | 45 @ 250MHz | 920MHz | - | -55°C ~ 125°C | 100 MHz | - | Surface Mount | - | 0.095" L x 0.070" W (2.41mm x 1.78mm) | 0.060" (1.52mm) |
|
|
CC0603-180GSCERAMIC SMT CHIP INDUCTOR |
1,734 |
|
Datasheet |
CC0603 | Nonstandard | Tape & Reel (TR) | Active | - | Ceramic | 180 nH | ±2% | 235 mA | - | Unshielded | 1.28Ohm Max | 25 @ 150MHz | 990MHz | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.071" L x 0.044" W (1.80mm x 1.12mm) | 0.040" (1.02mm) |
|
|
CC0603-100GSCERAMIC SMT CHIP INDUCTOR |
1,941 |
|
Datasheet |
CC0603 | Nonstandard | Tape & Reel (TR) | Active | - | Ceramic | 100 nH | ±2% | 308 mA | - | Unshielded | 747mOhm Max | 34 @ 150MHz | 1.4GHz | - | -40°C ~ 125°C | - | - | Surface Mount | - | 0.071" L x 0.044" W (1.80mm x 1.12mm) | 0.040" (1.02mm) |
|
|
CC0805-0047GSCERAMIC SMT CHIP INDUCTOR |
3,506 |
|
Datasheet |
CC0805 | 0805 (2012 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 4.7 nH | ±2% | 1 A | - | Unshielded | 80mOhm | 60 @ 1.5GHz | 5GHz | - | -55°C ~ 125°C | 250 MHz | - | Surface Mount | 0805 | 0.095" L x 0.070" W (2.41mm x 1.78mm) | 0.060" (1.52mm) |
|
|
CC0805-120GSCERAMIC SMT CHIP INDUCTOR |
2,708 |
|
Datasheet |
CC0805 | Nonstandard | Tape & Reel (TR) | Active | - | Ceramic | 120 nH | ±2% | 470 mA | - | Unshielded | 510mOhm Max | 45 @ 250MHz | 1.1GHz | - | -55°C ~ 125°C | 150 MHz | - | Surface Mount | - | 0.095" L x 0.070" W (2.41mm x 1.78mm) | 0.060" (1.52mm) |
|
VLM10555T-R33M180-3FIXED IND 330NH 18A 1.2 MOHM SMD |
3,189 |
|
Datasheet |
VLM | Nonstandard | Tape & Reel (TR) | Last Time Buy | Drum Core, Wirewound | Ferrite | 330 nH | ±20% | 18 A | 34A | Shielded | 1.2mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.417" L x 0.413" W (10.60mm x 10.50mm) | 0.220" (5.60mm) |
|
PL9509TFIXED IND 15UH 1.1A 82 MOHM SMD |
2,020 |
|
Datasheet |
PL95XX | Nonstandard | Tape & Reel (TR) | Active | - | - | 15 µH | ±20% | 1.1 A | 1.1A | Shielded | 82mOhm Max | - | - | - | -55°C ~ 130°C | - | - | Surface Mount | - | 0.256" L x 0.256" W (6.50mm x 6.50mm) | 0.122" (3.10mm) |
|
|
FPV1507-500-RFIXED IND 500NH 25A SMD |
4,979 |
|
- |
FPV1507 | Nonstandard | Tape & Reel (TR) | Active | - | - | 500 nH | - | 25 A | - | - | - | - | - | - | - | - | - | Surface Mount | - | 0.575" L x 0.327" W (14.60mm x 8.30mm) | 0.260" (6.60mm) |
|
|
1537-30GFIXED IND 5.6UH 565MA 320MOHM TH |
1,833 |
|
Datasheet |
1537 | Axial | Tape & Reel (TR) | Active | Molded | Iron | 5.6 µH | ±2% | 565 mA | - | Unshielded | 320mOhm Max | 45 @ 7.9MHz | 60MHz | - | -55°C ~ 105°C | 7.9 MHz | - | Through Hole | - | 0.156" Dia x 0.375" L (3.96mm x 9.53mm) | - |
|
|
1537-32GFIXED IND 6.8UH 450MA 500MOHM TH |
1,231 |
|
Datasheet |
1537 | Axial | Tape & Reel (TR) | Active | Molded | Iron | 6.8 µH | ±2% | 450 mA | - | Unshielded | 500mOhm Max | 50 @ 7.9MHz | 55MHz | - | -55°C ~ 105°C | 7.9 MHz | - | Through Hole | - | 0.156" Dia x 0.375" L (3.96mm x 9.53mm) | - |
|
|
1537-34GFIXED IND 8.2UH 410MA 600MOHM TH |
3,656 |
|
Datasheet |
1537 | Axial | Tape & Reel (TR) | Active | Molded | Iron | 8.2 µH | ±2% | 410 mA | - | Unshielded | 600mOhm Max | 50 @ 7.9MHz | 50MHz | - | -55°C ~ 105°C | 7.9 MHz | - | Through Hole | - | 0.156" Dia x 0.375" L (3.96mm x 9.53mm) | - |
|
|
1537-36GFIXED IND 10UH 335MA 900 MOHM TH |
1,587 |
|
Datasheet |
1537 | Axial | Tape & Reel (TR) | Active | Molded | Iron | 10 µH | ±2% | 335 mA | - | Unshielded | 900mOhm Max | 55 @ 7.9MHz | 45MHz | - | -55°C ~ 105°C | 7.9 MHz | - | Through Hole | - | 0.156" Dia x 0.375" L (3.96mm x 9.53mm) | - |
|
|
1537-38GFIXED IND 12UH 305MA 1.1 OHM TH |
3,966 |
|
Datasheet |
1537 | Axial | Tape & Reel (TR) | Active | Molded | Iron | 12 µH | ±2% | 305 mA | - | Unshielded | 1.1Ohm Max | 65 @ 2.5MHz | 42MHz | - | -55°C ~ 105°C | 2.5 MHz | - | Through Hole | - | 0.156" Dia x 0.375" L (3.96mm x 9.53mm) | - |
