Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
2300LL-560-H-RCFIXED IND 56UH 8.9A 20 MOHM TH |
2,411 |
|
Datasheet |
2300LL | Radial, Horizontal (Open) | Bulk | Active | Toroidal | Sendust | 56 µH | ±15% | 8.9 A | - | Shielded | 20mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | - | 1.280" Dia (32.51mm) | 0.650" (16.51mm) |
|
|
2300LL-680-H-RCFIXED IND 68UH 8.5A 23 MOHM TH |
2,381 |
|
Datasheet |
2300LL | Radial, Horizontal (Open) | Bulk | Active | Toroidal | Sendust | 68 µH | ±15% | 8.5 A | - | Shielded | 23mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | - | 1.280" Dia (32.51mm) | 0.650" (16.51mm) |
|
|
2300LL-820-H-RCFIXED IND 82UH 8.1A 25 MOHM TH |
3,672 |
|
Datasheet |
2300LL | Radial, Horizontal (Open) | Bulk | Active | Toroidal | Sendust | 82 µH | ±15% | 8.1 A | - | Shielded | 25mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | - | 1.280" Dia (32.51mm) | 0.650" (16.51mm) |
|
|
2300LL-121-H-RCFIXED IND 120UH 7.4A 30 MOHM TH |
2,217 |
|
Datasheet |
2300LL | Radial, Horizontal (Open) | Bulk | Active | Toroidal | Sendust | 120 µH | ±15% | 7.4 A | - | Shielded | 30mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | - | 1.280" Dia (32.51mm) | 0.650" (16.51mm) |
|
|
2300LL-151-H-RCFIXED IND 150UH 7A 33 MOHM TH |
3,070 |
|
Datasheet |
2300LL | Radial, Horizontal (Open) | Bulk | Active | Toroidal | Sendust | 150 µH | ±15% | 7 A | - | Shielded | 33mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | - | 1.280" Dia (32.51mm) | 0.650" (16.51mm) |
|
|
2300LL-181-H-RCFIXED IND 180UH 6.7A 37 MOHM TH |
3,698 |
|
Datasheet |
2300LL | Radial, Horizontal (Open) | Bulk | Active | Toroidal | Sendust | 180 µH | ±15% | 6.7 A | - | Shielded | 37mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | - | 1.280" Dia (32.51mm) | 0.650" (16.51mm) |
|
|
2300LL-221-H-RCFIXED IND 220UH 5.1A 63 MOHM TH |
4,281 |
|
Datasheet |
2300LL | Radial, Horizontal (Open) | Bulk | Active | Toroidal | Sendust | 220 µH | ±15% | 5.1 A | - | Shielded | 63mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | - | 1.280" Dia (32.51mm) | 0.650" (16.51mm) |
|
|
2300LL-471-H-RCFIXED IND 470UH 4.2A 94 MOHM TH |
1,311 |
|
Datasheet |
2300LL | Radial, Horizontal (Open) | Bulk | Active | Toroidal | Sendust | 470 µH | ±15% | 4.2 A | - | Shielded | 94mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | - | 1.280" Dia (32.51mm) | 0.650" (16.51mm) |
|
|
2300LL-821-H-RCFIXED IND 820UH 3.6A 123 MOHM TH |
4,712 |
|
Datasheet |
2300LL | Radial, Horizontal (Open) | Bulk | Active | Toroidal | Sendust | 820 µH | ±15% | 3.6 A | - | Shielded | 123mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | - | 1.280" Dia (32.51mm) | 0.650" (16.51mm) |
|
1210R-150KFIXED IND 15NH 871MA 160MOHM SMD |
2,627 |
|
Datasheet |
1210R | 1210 (3225 Metric) | Tape & Reel (TR) | Active | - | Phenolic | 15 nH | ±10% | 871 mA | - | Unshielded | 160mOhm Max | 30 @ 50MHz | 1.7GHz | - | -55°C ~ 125°C | 50 MHz | - | Surface Mount | 1210 | 0.128" L x 0.095" W (3.25mm x 2.42mm) | 0.101" (2.57mm) |
|
|
1210R-220KFIXED IND 22NH 779MA 200MOHM SMD |
2,000 |
|
Datasheet |
1210R | 1210 (3225 Metric) | Tape & Reel (TR) | Active | - | Phenolic | 22 nH | ±10% | 779 mA | - | Unshielded | 200mOhm Max | 30 @ 50MHz | 1.3GHz | - | -55°C ~ 125°C | 50 MHz | - | Surface Mount | 1210 | 0.128" L x 0.095" W (3.25mm x 2.42mm) | 0.101" (2.57mm) |
|
|
1210R-271KFIXED IND 270NH 759MA 360MOHM SM |
1,120 |
|
Datasheet |
1210R | 1210 (3225 Metric) | Tape & Reel (TR) | Active | - | Iron | 270 nH | ±10% | 759 mA | - | Unshielded | 360mOhm Max | 30 @ 25MHz | 320MHz | - | -55°C ~ 125°C | 25 MHz | - | Surface Mount | 1210 | 0.128" L x 0.095" W (3.25mm x 2.42mm) | 0.101" (2.57mm) |
|
|
1210R-471KFIXED IND 470NH 644MA 500MOHM SM |
2,599 |
|
Datasheet |
1210R | 1210 (3225 Metric) | Tape & Reel (TR) | Active | - | Iron | 470 nH | ±10% | 644 mA | - | Unshielded | 500mOhm Max | 30 @ 25MHz | 220MHz | - | -55°C ~ 125°C | 25 MHz | - | Surface Mount | 1210 | 0.128" L x 0.095" W (3.25mm x 2.42mm) | 0.101" (2.57mm) |
|
|
1210R-561KFIXED IND 560NH 614MA 550MOHM SM |
4,635 |
|
Datasheet |
1210R | 1210 (3225 Metric) | Tape & Reel (TR) | Active | - | Iron | 560 nH | ±10% | 614 mA | - | Unshielded | 550mOhm Max | 30 @ 25MHz | 180MHz | - | -55°C ~ 125°C | 25 MHz | - | Surface Mount | 1210 | 0.128" L x 0.095" W (3.25mm x 2.42mm) | 0.101" (2.57mm) |
|
|
1210R-680KFIXED IND 68NH 580MA 360MOHM SMD |
2,379 |
|
Datasheet |
1210R | 1210 (3225 Metric) | Tape & Reel (TR) | Active | - | Phenolic | 68 nH | ±10% | 580 mA | - | Unshielded | 360mOhm Max | 30 @ 50MHz | 700MHz | - | -55°C ~ 125°C | 50 MHz | - | Surface Mount | 1210 | 0.128" L x 0.095" W (3.25mm x 2.42mm) | 0.101" (2.57mm) |
|
|
1210R-681KFIXED IND 680NH 588MA 600MOHM SM |
4,991 |
|
Datasheet |
1210R | 1210 (3225 Metric) | Tape & Reel (TR) | Active | - | Iron | 680 nH | ±10% | 588 mA | - | Unshielded | 600mOhm Max | 30 @ 25MHz | 160MHz | - | -55°C ~ 125°C | 25 MHz | - | Surface Mount | 1210 | 0.128" L x 0.095" W (3.25mm x 2.42mm) | 0.101" (2.57mm) |
|
BPSP001909112R0M00INDUCTOR POWER |
4,817 |
|
Datasheet |
BPSP | Nonstandard, 3 Lead | Tape & Reel (TR) | Active | Wirewound | - | 2 µH | ±20% | 40 A | 34.4A | Shielded | 1.4mOhm Max | - | 39MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.748" L x 0.736" W (19.00mm x 18.70mm) | 0.420" (10.67mm) |
|
IHSM7832ER1R5LFIXED IND 1.5UH 8.6A 12 MOHM SMD |
4,113 |
|
Datasheet |
IHSM-7832 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 1.5 µH | ±15% | 8.6 A | 4.4A | Unshielded | 12mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.840" L x 0.320" W (21.34mm x 8.13mm) | 0.285" (7.24mm) |
|
|
IHSM7832ER1R8LFIXED IND 1.8UH 8.5A 13 MOHM SMD |
1,113 |
|
Datasheet |
IHSM-7832 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 1.8 µH | ±15% | 8.5 A | 4A | Unshielded | 13mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.840" L x 0.320" W (21.34mm x 8.13mm) | 0.285" (7.24mm) |
|
|
IHSM7832ER2R7LFIXED IND 2.7UH 8.2A 16 MOHM SMD |
4,228 |
|
Datasheet |
IHSM-7832 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 2.7 µH | ±15% | 8.2 A | 3.2A | Unshielded | 16mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.840" L x 0.320" W (21.34mm x 8.13mm) | 0.285" (7.24mm) |
