Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
S0402-8N2J1YROHS, SURFACE MOUNT, WIREWOUND 0 |
2,484 |
|
Datasheet |
S0402 | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 8.2 nH | ±5% | 600 mA | - | Unshielded | 130mOhm Max | 22 @ 100MHz | 4.4GHz | - | -55°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.040" L x 0.022" W (1.02mm x 0.55mm) | 0.030" (0.76mm) |
|
|
S0402-4N7J1YROHS, SURFACE MOUNT, WIREWOUND 0 |
4,531 |
|
Datasheet |
S0402 | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 4.7 nH | ±5% | 600 mA | - | Unshielded | 150mOhm Max | 22 @ 100MHz | 4.7GHz | - | -55°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.040" L x 0.022" W (1.02mm x 0.55mm) | 0.030" (0.76mm) |
|
|
S0402-12NJ1YROHS, SURFACE MOUNT, WIREWOUND 0 |
2,202 |
|
Datasheet |
S0402 | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 12 nH | ±5% | 475 mA | - | Unshielded | 220mOhm Max | 22 @ 100MHz | 3.6GHz | - | -55°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.040" L x 0.022" W (1.02mm x 0.55mm) | 0.030" (0.76mm) |
|
|
S0402-15NJ1YROHS, SURFACE MOUNT, WIREWOUND 0 |
4,419 |
|
Datasheet |
S0402 | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 15 nH | ±5% | 475 mA | - | Unshielded | 220mOhm Max | 22 @ 100MHz | 3.28GHz | - | -55°C ~ 125°C | 250 MHz | - | Surface Mount | 0402 | 0.040" L x 0.022" W (1.02mm x 0.55mm) | 0.030" (0.76mm) |
|
103-102KSFIXED IND 1UH 425MA 540 MOHM SMD |
2,489 |
|
Datasheet |
103 | Nonstandard, 2 Lead | Tape & Reel (TR) | Active | - | Ferrite | 1 µH | ±10% | 425 mA | - | Unshielded | 540mOhm Max | 22 @ 25MHz | 145MHz | - | -55°C ~ 125°C | 25 MHz | - | Surface Mount | - | 0.100" L x 0.100" W (2.54mm x 2.54mm) | 0.075" (1.91mm) |
|
|
S0603-221NJ1YROHS, SURFACE MOUNT, WIREWOUND 0 |
2,189 |
|
Datasheet |
S0603 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 220 nH | ±5% | 250 mA | - | Unshielded | 1.7Ohm Max | 22 @ 100MHz | 1.2GHz | - | -55°C ~ 125°C | 100 MHz | - | Surface Mount | 0603 | 0.060" L x 0.031" W (1.52mm x 0.80mm) | 0.040" (1.02mm) |
|
|
S0603-151NJ1YROHS, SURFACE MOUNT, WIREWOUND 0 |
2,478 |
|
Datasheet |
S0603 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 150 nH | ±5% | 280 mA | - | Unshielded | 980mOhm Max | 29 @ 100MHz | 1.3GHz | - | -55°C ~ 125°C | 100 MHz | - | Surface Mount | 0603 | 0.060" L x 0.031" W (1.52mm x 0.80mm) | 0.040" (1.02mm) |
|
|
S0603-271NJ1YROHS, SURFACE MOUNT, WIREWOUND 0 |
4,825 |
|
Datasheet |
S0603 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 270 nH | ±5% | 200 mA | - | Unshielded | 2.2Ohm Max | 22 @ 100MHz | 900MHz | - | -55°C ~ 125°C | 100 MHz | - | Surface Mount | 0603 | 0.060" L x 0.031" W (1.52mm x 0.80mm) | 0.040" (1.02mm) |
|
|
S0603-82NJ1YROHS, SURFACE MOUNT, WIREWOUND 0 |
3,692 |
|
Datasheet |
S0603 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 82 nH | ±5% | 400 mA | - | Unshielded | 570mOhm Max | 34 @ 150MHz | 1.7GHz | - | -55°C ~ 125°C | 150 MHz | - | Surface Mount | 0603 | 0.060" L x 0.031" W (1.52mm x 0.80mm) | 0.040" (1.02mm) |
|
|
S0603-33NJ1YROHS, SURFACE MOUNT, WIREWOUND 0 |
2,982 |
|
Datasheet |
S0603 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 33 nH | ±5% | 600 mA | - | Unshielded | 250mOhm Max | 37 @ 250MHz | 2.3GHz | - | -55°C ~ 125°C | 250 MHz | - | Surface Mount | 0603 | 0.060" L x 0.031" W (1.52mm x 0.80mm) | 0.040" (1.02mm) |
|
|
S0603-47NJ1YROHS, SURFACE MOUNT, WIREWOUND 0 |
2,838 |
|
Datasheet |
S0603 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 47 nH | ±5% | 600 mA | - | Unshielded | 310mOhm Max | 35 @ 200MHz | 2GHz | - | -55°C ~ 125°C | 200 MHz | - | Surface Mount | 0603 | 0.060" L x 0.031" W (1.52mm x 0.80mm) | 0.040" (1.02mm) |
|
|
S0603-68NJ1YROHS, SURFACE MOUNT, WIREWOUND 0 |
4,241 |
|
Datasheet |
S0603 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 68 nH | ±5% | 600 mA | - | Unshielded | 370mOhm Max | 34 @ 200MHz | 1.7GHz | - | -55°C ~ 125°C | 200 MHz | - | Surface Mount | 0603 | 0.060" L x 0.031" W (1.52mm x 0.80mm) | 0.040" (1.02mm) |
|
|
S0603-56NJ1YROHS, SURFACE MOUNT, WIREWOUND 0 |
3,695 |
|
Datasheet |
S0603 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 56 nH | ±5% | 600 mA | - | Unshielded | 340mOhm Max | 35 @ 200MHz | 1.9GHz | - | -55°C ~ 125°C | 200 MHz | - | Surface Mount | 0603 | 0.060" L x 0.031" W (1.52mm x 0.80mm) | 0.040" (1.02mm) |
|
|
S0603-101NJ1YROHS, SURFACE MOUNT, WIREWOUND 0 |
4,752 |
|
Datasheet |
S0603 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 100 nH | ±5% | 400 mA | - | Unshielded | 610mOhm Max | 31 @ 150MHz | 1.4GHz | - | -55°C ~ 125°C | 150 MHz | - | Surface Mount | 0603 | 0.060" L x 0.031" W (1.52mm x 0.80mm) | 0.040" (1.02mm) |
|
|
S0603-39NJ1YROHS, SURFACE MOUNT, WIREWOUND 0 |
3,674 |
|
Datasheet |
S0603 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 39 nH | ±5% | 600 mA | - | Unshielded | 280mOhm Max | 37 @ 250MHz | 2.2GHz | - | -55°C ~ 125°C | 250 MHz | - | Surface Mount | 0603 | 0.060" L x 0.031" W (1.52mm x 0.80mm) | 0.040" (1.02mm) |
|
CTX08-13679FIXED IND 1.2MH 4.7A 67 MOHM TH |
3,115 |
|
Datasheet |
PFC | Radial, 10 Leads | Bulk | Obsolete | Toroidal | Ferrite | 1.2 mH | ±3% | 4.7 A | - | Unshielded | 67mOhm Max | - | - | - | -20°C ~ 105°C | 100 kHz | - | Through Hole | - | 2.020" L x 1.900" W (51.31mm x 48.26mm) | 1.530" (38.86mm) |
|
|
S0603-10NJ1YROHS, SURFACE MOUNT, WIREWOUND 0 |
3,553 |
|
Datasheet |
S0603 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 10 nH | ±5% | 700 mA | - | Unshielded | 160mOhm Max | 28 @ 250MHz | 4.8GHz | - | -55°C ~ 125°C | 250 MHz | - | Surface Mount | 0603 | 0.060" L x 0.031" W (1.52mm x 0.80mm) | 0.040" (1.02mm) |
|
|
S0603-8N2J1YROHS, SURFACE MOUNT, WIREWOUND 0 |
3,421 |
|
Datasheet |
S0603 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 8.2 nH | ±5% | 700 mA | - | Unshielded | 150mOhm Max | 24 @ 250MHz | 4.8GHz | - | -55°C ~ 125°C | 250 MHz | - | Surface Mount | 0603 | 0.060" L x 0.031" W (1.52mm x 0.80mm) | 0.040" (1.02mm) |
|
|
S0603-22NJ1YROHS, SURFACE MOUNT, WIREWOUND 0 |
1,446 |
|
Datasheet |
S0603 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 22 nH | ±5% | 700 mA | - | Unshielded | 220mOhm Max | 35 @ 250MHz | 3GHz | - | -55°C ~ 125°C | 250 MHz | - | Surface Mount | 0603 | 0.060" L x 0.031" W (1.52mm x 0.80mm) | 0.040" (1.02mm) |
|
|
S0603-3N3J1YROHS, SURFACE MOUNT, WIREWOUND 0 |
3,967 |
|
Datasheet |
S0603 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | - | 3.3 nH | ±5% | 700 mA | - | Unshielded | 100mOhm Max | 18 @ 250MHz | 6GHz | - | -55°C ~ 125°C | 250 MHz | - | Surface Mount | 0603 | 0.060" L x 0.031" W (1.52mm x 0.80mm) | 0.040" (1.02mm) |
