Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
XGL4025-901MECFIXED INDUCTOR 0.9UH SMD |
2,578 |
|
Datasheet |
XGL4025 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 900 nH | ±20% | 13.7 A | 9.6A | Shielded | 7.4mOhm Max | - | 63MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.098" (2.50mm) |
|
XEL4020-561MECFIXED IND 560NH 13.8A 8.8MOHM SM |
2,572 |
|
Datasheet |
XEL4020 | 1616 (4040 Metric) | Tape & Reel (TR) | Active | Molded | Metal Composite | 560 nH | ±20% | 13.8 A | 11.3A | Shielded | 8.8mOhm Max | - | 90MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.083" (2.10mm) |
|
|
XGL4025-682MECFIXED INDUCTOR 6.8UH SMD |
2,510 |
|
Datasheet |
XGL4025 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 6.8 µH | ±20% | 4.5 A | 3.5A | Shielded | 58.7mOhm Max | - | 22MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.098" (2.50mm) |
|
|
XEL4020-821MECFIXED IND 820NH 11.5A 13MOHM SM |
2,321 |
|
Datasheet |
XEL4020 | 1616 (4040 Metric) | Tape & Reel (TR) | Active | Molded | Metal Composite | 820 nH | ±20% | 11.5 A | 10.2A | Shielded | 13mOhm Max | - | 69MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.083" (2.10mm) |
|
|
XGL4025-122MECFIXED INDUCTOR 1.2UH SMD |
2,234 |
|
Datasheet |
XGL4025 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 1.2 µH | ±20% | 11.3 A | 8.2A | Shielded | 10mOhm Max | - | 53MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.098" (2.50mm) |
|
|
XGL4025-131MECFIXED INDUCTOR 0.13UH SMD |
2,190 |
|
Datasheet |
XGL4025 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 130 nH | ±20% | 28 A | 24A | Shielded | 1.7mOhm Max | - | 230MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.098" (2.50mm) |
|
|
XGL4025-332MECFIXED INDUCTOR 3.3UH SMD |
2,167 |
|
Datasheet |
XGL4025 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 3.3 µH | ±20% | 6.9 A | 4.9A | Shielded | 27mOhm Max | - | 32MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.098" (2.50mm) |
|
|
XGL4025-222MECFIXED INDUCTOR 2.2UH SMD |
2,160 |
|
Datasheet |
XGL4025 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 2.2 µH | ±20% | 9 A | 6.3A | Shielded | 16.9mOhm Max | - | 40MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.098" (2.50mm) |
|
|
XGL4025-681MECFIXED INDUCTOR 0.68UH SMD |
2,053 |
|
Datasheet |
XGL4025 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 680 nH | ±20% | 16.4 A | 11A | Shielded | 6.3mOhm Max | - | 77MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.098" (2.50mm) |
|
|
XGL4025-821MECFIXED INDUCTOR 0.82UH SMD |
2,037 |
|
Datasheet |
XGL4025 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 820 nH | ±20% | 14.4 A | 10.1A | Shielded | 7.2mOhm Max | - | 68MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.098" (2.50mm) |
|
|
XGL4025-152MECFIXED INDUCTOR 1.5UH SMD |
2,010 |
|
Datasheet |
XGL4025 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 1.5 µH | ±20% | 11 A | 7.6A | Shielded | 12mOhm Max | - | 49MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.098" (2.50mm) |
|
|
XGL4025-102MECFIXED INDUCTOR 1UH SMD |
1,640 |
|
Datasheet |
XGL4025 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 1 µH | ±20% | 13.1 A | 8.9A | Shielded | 8.5mOhm Max | - | 58MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.098" (2.50mm) |
|
|
XGL4025-472MECFIXED INDUCTOR 4.7UH SMD |
1,527 |
|
Datasheet |
XGL4025 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 4.7 µH | ±20% | 5.4 A | 4.3A | Shielded | 39.5mOhm Max | - | 26MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.098" (2.50mm) |
|
|
XEL4020-101MECFIXED IND 100NH 19.9A 2.5MOHM SM |
1,518 |
|
Datasheet |
XEL4020 | 1616 (4040 Metric) | Tape & Reel (TR) | Active | Molded | Metal Composite | 100 nH | ±20% | 19.9 A | 28.5A | Shielded | 2.5mOhm Max | - | 280MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.083" (2.10mm) |
|
|
XEL4020-222MECFIXED IND 2.2UH 5.5A 38.7MOHM SM |
1,466 |
|
Datasheet |
XEL4020 | 1616 (4040 Metric) | Tape & Reel (TR) | Active | Molded | Metal Composite | 2.2 µH | ±20% | 5.5 A | 5.9A | Shielded | 38.7mOhm Max | - | 41MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.083" (2.10mm) |
|
|
XGL4025-103MECFIXED INDUCTOR 10UH SMD |
1,013 |
|
Datasheet |
XGL4025 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 10 µH | ±20% | 3.6 A | 2.9A | Shielded | 89.2mOhm Max | - | 18MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.098" (2.50mm) |
|
|
HA72E-121R0HLFTR13FIXED IND 1UH 32A 2 MOHM SMD |
800 |
|
Datasheet |
HA72E-12 | Nonstandard | Tape & Reel (TR) | Discontinued at Digi-Key | Molded | - | 1 µH | ±20% | 32 A | 31A | Unshielded | 2mOhm Max | - | - | AEC-Q200 | -40°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.549" L x 0.512" W (13.95mm x 13.00mm) | 0.256" (6.50mm) |
|
|
XGL4025-471MECFIXED INDUCTOR 0.47UH SMD |
745 |
|
Datasheet |
XGL4025 | 1616 (4040 Metric) | Strip | Active | Molded | Metal Composite | 470 nH | ±20% | 17.8 A | 13.5A | Shielded | 4.5mOhm Max | - | 100MHz | AEC-Q200 | -40°C ~ 125°C | 1 MHz | - | Surface Mount | 1616 | 0.157" L x 0.157" W (4.00mm x 4.00mm) | 0.098" (2.50mm) |
|
|
VSEB0730H-3R3MCAUTOMOTIVE SMD MOLDING POWER CHK |
500 |
|
Datasheet |
VSEB0730H | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 3.3 µH | ±20% | 11.3 A | 9.3A | Shielded | 15.8mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | Molded Inductors, Automotive Grade Power Inductors | Surface Mount | 2-SMD | 0.311" L x 0.299" W (7.90mm x 7.60mm) | 0.118" (3.00mm) |
|
|
VSEB0430H-R68MCAUTOMOTIVE SMD MOLDING POWER CHK |
500 |
|
Datasheet |
VSEB0430H | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 0.68 µH | ±20% | 15 A | 11A | Shielded | 6.3mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | Molded Inductors, Automotive Grade Power Inductors | Surface Mount | 2-SMD | 0.169" L x 0.169" W (4.30mm x 4.30mm) | 0.118" (3.00mm) |
