Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MGV0503R68M-10FIXED IND 680NH 10.2A 8.96 MOHM |
495 |
|
Datasheet |
MGV | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 680 nH | ±20% | 10.2 A | 13.5A | Shielded | 8.96mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.217" L x 0.201" W (5.50mm x 5.10mm) | 0.130" (3.30mm) |
|
|
MGV0503R82M-10FIXED IND 820NH 9.3A 11.9MOHM SM |
490 |
|
Datasheet |
MGV | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 820 nH | ±20% | 9.3 A | 13A | Shielded | 11.9mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.217" L x 0.201" W (5.50mm x 5.10mm) | 0.130" (3.30mm) |
|
|
MGV0503R22M-10FIXED IND 220NH 15.5A 4.52 MOHM |
450 |
|
Datasheet |
MGV | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 220 nH | ±20% | 15.5 A | 21A | Shielded | 4.52mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.217" L x 0.201" W (5.50mm x 5.10mm) | 0.130" (3.30mm) |
|
LTF5022T-330MR77-DFIXED IND 33UH 850MA 490MOHM SMD |
420 |
|
Datasheet |
LTF5022T | Nonstandard | Tape & Reel (TR) | Last Time Buy | Drum Core, Wirewound | Ferrite | 33 µH | ±20% | 850 mA | 770mA | Shielded | 490mOhm Max | - | - | AEC-Q200 | -40°C ~ 105°C | 100 kHz | - | Surface Mount | - | 0.256" L x 0.197" W (6.50mm x 5.00mm) | 0.087" (2.20mm) |
|
|
LTF5022T-1R8N3R1-DFIXED IND 1.8UH 3.1A 37 MOHM SMD |
260 |
|
Datasheet |
LTF5022T | Nonstandard | Tape & Reel (TR) | Last Time Buy | Drum Core, Wirewound | Ferrite | 1.8 µH | ±30% | 3.1 A | 3.2A | Shielded | 37mOhm Max | - | - | AEC-Q200 | -40°C ~ 105°C | 100 kHz | - | Surface Mount | - | 0.256" L x 0.197" W (6.50mm x 5.00mm) | 0.087" (2.20mm) |
|
HCM1A1104-3R3-RFIXED IND 3.3UH 8.2A 11.8MOHM SM |
2,925 |
|
Datasheet |
HCM1A | Nonstandard | Tape & Reel (TR) | Active | - | Iron Powder | 3.3 µH | ±20% | 8.2 A | 11.5A | Shielded | 11.8mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.453" L x 0.406" W (11.50mm x 10.30mm) | 0.157" (4.00mm) |
|
|
HCM1A1104-1R5-RFIXED IND 1.5UH 14A 4.2MOHM SMD |
3,240 |
|
Datasheet |
HCM1A | Nonstandard | Tape & Reel (TR) | Active | - | Iron Powder | 1.5 µH | ±20% | 14 A | 17A | Shielded | 4.2mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.453" L x 0.406" W (11.50mm x 10.30mm) | 0.157" (4.00mm) |
|
LPS5015-102MRCPOWER INDUCTOR, SHIELDED, 20% TO |
44,380 |
|
Datasheet |
LPS5015 | Nonstandard | Strip | Active | Drum Core | Ferrite | 1 µH | ±20% | 1.9 A | 3.6A | Shielded | 50mOhm Max | - | 183MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.197" L x 0.197" W (5.00mm x 5.00mm) | 0.059" (1.50mm) |
|
|
LPS5015-683MRCPOWER INDUCTOR, SHIELDED, 20% TO |
31,338 |
|
Datasheet |
LPS5015 | Nonstandard | Strip | Active | Drum Core | Ferrite | 68 µH | ±20% | 350 mA | 330mA | Shielded | 1.45Ohm Max | - | 15MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.197" L x 0.197" W (5.00mm x 5.00mm) | 0.059" (1.50mm) |
|
|
LPS5015-105MRCPOWER INDUCTOR, SHIELDED, 20% TO |
4,543 |
|
Datasheet |
LPS5015 | Nonstandard | Strip | Active | Drum Core | Ferrite | 1 mH | ±20% | 100 mA | 80mA | Shielded | 15Ohm Max | - | 3.2MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.197" L x 0.197" W (5.00mm x 5.00mm) | 0.059" (1.50mm) |
|
|
LPS5015-103MRCPOWER INDUCTOR, SHIELDED, 20% TO |
3,774 |
|
Datasheet |
LPS5015 | Nonstandard | Strip | Active | Drum Core | Ferrite | 10 µH | ±20% | 800 mA | 1.2A | Shielded | 300mOhm Max | - | 44MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.197" L x 0.197" W (5.00mm x 5.00mm) | 0.059" (1.50mm) |
|
|
LPS5015-222MRCPOWER INDUCTOR, SHIELDED, 20% TO |
3,236 |
|
Datasheet |
LPS5015 | Nonstandard | Strip | Active | Drum Core | Ferrite | 2.2 µH | ±20% | 1.4 A | 2.4A | Shielded | 90mOhm Max | - | 116MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.197" L x 0.197" W (5.00mm x 5.00mm) | 0.059" (1.50mm) |
|
CTCH110F-271K270UH RADIAL LEAD FIXED INDUCTOR |
3,000 |
|
- |
CTCH110F | Radial, Vertical Cylinder, 4 Leads | Bulk | Active | Wirewound | - | 270 µH | ±10% | - | 1A | Unshielded | 400mOhm Max | - | - | - | - | 1 kHz | - | Through Hole | Radial | 0.394" Dia (10.00mm) | 0.413" (10.50mm) |
|
CTCDRH125F-121M120UH SMD SHIELDED POWR INDUCTOR |
2,940 |
|
Datasheet |
CTCDRH125F | Nonstandard | Tape & Reel (TR) | Active | - | - | 120 µH | ±20% | - | 1.1A | Shielded | 170mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Surface Mount | - | 0.504" L x 0.504" W (12.80mm x 12.80mm) | 0.236" (6.00mm) |
|
0840CDMCCDS-1R0MCFIXED IND 1UH 16.5A 5.6MOHM SMD |
2,456 |
|
Datasheet |
0840CDMCC/DS | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal | 1 µH | ±20% | 16.5 A | 15.3A | Shielded | 5.6mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.319" L x 0.307" W (8.10mm x 7.80mm) | 0.157" (4.00mm) |
|
|
LPS5015-332MRCPOWER INDUCTOR, SHIELDED, 20% TO |
1,572 |
|
Datasheet |
LPS5015 | Nonstandard | Strip | Active | Drum Core | Ferrite | 3.3 µH | ±20% | 1.3 A | 1.9A | Shielded | 125mOhm Max | - | 88MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.197" L x 0.197" W (5.00mm x 5.00mm) | 0.059" (1.50mm) |
|
|
LPS5015-473MRCPOWER INDUCTOR, SHIELDED, 20% TO |
1,552 |
|
Datasheet |
LPS5015 | Nonstandard | Strip | Active | Drum Core | Ferrite | 47 µH | ±20% | 450 mA | 460mA | Shielded | 1Ohm Max | - | 18MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.197" L x 0.197" W (5.00mm x 5.00mm) | 0.059" (1.50mm) |
|
|
LPS5015-104MRCPOWER INDUCTOR, SHIELDED, 20% TO |
1,353 |
|
Datasheet |
LPS5015 | Nonstandard | Strip | Active | Drum Core | Ferrite | 100 µH | ±20% | 300 mA | 300mA | Shielded | 1.95Ohm Max | - | 12MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.197" L x 0.197" W (5.00mm x 5.00mm) | 0.059" (1.50mm) |
|
|
LPS5015-123MRCPOWER INDUCTOR, SHIELDED, 20% TO |
1,279 |
|
Datasheet |
LPS5015 | Nonstandard | Strip | Active | Drum Core | Ferrite | 12 µH | ±20% | 750 mA | 1A | Shielded | 350mOhm Max | - | 40MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.197" L x 0.197" W (5.00mm x 5.00mm) | 0.059" (1.50mm) |
|
|
0840CDMCCDS-R68MCFIXED IND 680NH 18A 4.3MOHM SMD |
1,266 |
|
Datasheet |
0840CDMCC/DS | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal | 680 nH | ±20% | 18 A | 17.5A | Shielded | 4.3mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.319" L x 0.307" W (8.10mm x 7.80mm) | 0.157" (4.00mm) |
