Resistor Networks, Arrays
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Circuit Type | Resistance (Ohms) | Tolerance | Number of Resistors | Resistor Matching Ratio | Resistor-Ratio-Drift | Number of Pins | Power Per Element | Temperature Coefficient | Operating Temperature | Grade | Qualification | Applications | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
742C163392JPRES ARRAY 8 RES 3.9K OHM 2506 |
4,749 |
|
Datasheet |
742 | 2506, Concave, Long Side Terminals | Tape & Reel (TR) | Active | Isolated | 3.9k | ±5% | 8 | - | - | 16 | 63mW | ±200ppm/°C | -55°C ~ 125°C | - | - | DDR SDRAM, DRAM, MDDR | Surface Mount | - | 0.252" L x 0.063" W (6.40mm x 1.60mm) | 0.028" (0.70mm) |
|
|
742C163512JPRES ARRAY 8 RES 5.1K OHM 2506 |
3,134 |
|
Datasheet |
742 | 2506, Concave, Long Side Terminals | Tape & Reel (TR) | Active | Isolated | 5.1k | ±5% | 8 | - | - | 16 | 63mW | ±200ppm/°C | -55°C ~ 125°C | - | - | DDR SDRAM, DRAM, MDDR | Surface Mount | - | 0.252" L x 0.063" W (6.40mm x 1.60mm) | 0.028" (0.70mm) |
|
|
742C163560JPRES ARRAY 8 RES 56 OHM 2506 |
4,422 |
|
Datasheet |
742 | 2506, Concave, Long Side Terminals | Tape & Reel (TR) | Active | Isolated | 56 | ±5% | 8 | - | - | 16 | 63mW | ±200ppm/°C | -55°C ~ 125°C | - | - | DDR SDRAM, DRAM, MDDR | Surface Mount | - | 0.252" L x 0.063" W (6.40mm x 1.60mm) | 0.028" (0.70mm) |
|
|
742C163680JPRES ARRAY 8 RES 68 OHM 2506 |
3,707 |
|
Datasheet |
742 | 2506, Concave, Long Side Terminals | Tape & Reel (TR) | Active | Isolated | 68 | ±5% | 8 | - | - | 16 | 63mW | ±200ppm/°C | -55°C ~ 125°C | - | - | DDR SDRAM, DRAM, MDDR | Surface Mount | - | 0.252" L x 0.063" W (6.40mm x 1.60mm) | 0.028" (0.70mm) |
|
|
742C163681JPRES ARRAY 8 RES 680 OHM 2506 |
4,270 |
|
Datasheet |
742 | 2506, Concave, Long Side Terminals | Tape & Reel (TR) | Active | Isolated | 680 | ±5% | 8 | - | - | 16 | 63mW | ±200ppm/°C | -55°C ~ 125°C | - | - | DDR SDRAM, DRAM, MDDR | Surface Mount | - | 0.252" L x 0.063" W (6.40mm x 1.60mm) | 0.028" (0.70mm) |
|
|
742C163683JPRES ARRAY 8 RES 68K OHM 2506 |
1,231 |
|
Datasheet |
742 | 2506, Concave, Long Side Terminals | Tape & Reel (TR) | Active | Isolated | 68k | ±5% | 8 | - | - | 16 | 63mW | ±200ppm/°C | -55°C ~ 125°C | - | - | DDR SDRAM, DRAM, MDDR | Surface Mount | - | 0.252" L x 0.063" W (6.40mm x 1.60mm) | 0.028" (0.70mm) |
|
|
742C163750JPRES ARRAY 8 RES 75 OHM 2506 |
4,344 |
|
Datasheet |
742 | 2506, Concave, Long Side Terminals | Tape & Reel (TR) | Active | Isolated | 75 | ±5% | 8 | - | - | 16 | 63mW | ±200ppm/°C | -55°C ~ 125°C | - | - | DDR SDRAM, DRAM, MDDR | Surface Mount | - | 0.252" L x 0.063" W (6.40mm x 1.60mm) | 0.028" (0.70mm) |
|
|
742C163820JPRES ARRAY 8 RES 82 OHM 2506 |
1,028 |
|
Datasheet |
742 | 2506, Concave, Long Side Terminals | Tape & Reel (TR) | Active | Isolated | 82 | ±5% | 8 | - | - | 16 | 63mW | ±200ppm/°C | -55°C ~ 125°C | - | - | DDR SDRAM, DRAM, MDDR | Surface Mount | - | 0.252" L x 0.063" W (6.40mm x 1.60mm) | 0.028" (0.70mm) |
|
|
742C163822JPRES ARRAY 8 RES 8.2K OHM 2506 |
3,107 |
|
Datasheet |
742 | 2506, Concave, Long Side Terminals | Tape & Reel (TR) | Active | Isolated | 8.2k | ±5% | 8 | - | - | 16 | 63mW | ±200ppm/°C | -55°C ~ 125°C | - | - | DDR SDRAM, DRAM, MDDR | Surface Mount | - | 0.252" L x 0.063" W (6.40mm x 1.60mm) | 0.028" (0.70mm) |
|
EXB-F10V333GRES ARRAY 5 RES 33K OHM 10SIP |
3,452 |
|
- |
EXB | 10-SIP | Bulk | Obsolete | Isolated | 33k | ±2% | 5 | - | - | 10 | 200mW | ±200ppm/°C | -55°C ~ 125°C | - | - | - | Through Hole | 10-SIP | 0.986" L x 0.100" W (25.04mm x 2.54mm) | 0.195" (4.95mm) |
|
4609X-101-680LFRES ARRAY 8 RES 68 OHM 9SIP |
2,938 |
|
Datasheet |
4600X | 9-SIP | Bulk | Active | Bussed | 68 | ±2% | 8 | - | - | 9 | 200mW | ±100ppm/°C | -55°C ~ 125°C | - | - | - | Through Hole | 9-SIP | 0.898" L x 0.098" W (22.81mm x 2.49mm) | 0.200" (5.08mm) |
|
741X1631000FPRES ARRAY 8 RES 100 OHM 1506 |
3,338 |
|
Datasheet |
741 | 1506, Convex, Long Side Terminals | Tape & Reel (TR) | Active | Isolated | 100 | ±1% | 8 | - | - | 16 | 63mW | ±200ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | DDR SDRAM, DRAM, MDDR | Surface Mount | - | 0.156" L x 0.063" W (3.95mm x 1.60mm) | 0.022" (0.55mm) |
|
|
741X1631003FPRES ARRAY 8 RES 100K OHM 1506 |
2,875 |
|
Datasheet |
741 | 1506, Convex, Long Side Terminals | Tape & Reel (TR) | Active | Isolated | 100k | ±1% | 8 | - | - | 16 | 63mW | ±200ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | DDR SDRAM, DRAM, MDDR | Surface Mount | - | 0.156" L x 0.063" W (3.95mm x 1.60mm) | 0.022" (0.55mm) |
|
|
741X1633300FPRES ARRAY 8 RES 330 OHM 1506 |
3,361 |
|
Datasheet |
741 | 1506, Convex, Long Side Terminals | Tape & Reel (TR) | Active | Isolated | 330 | ±1% | 8 | - | - | 16 | 63mW | ±200ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | DDR SDRAM, DRAM, MDDR | Surface Mount | - | 0.156" L x 0.063" W (3.95mm x 1.60mm) | 0.022" (0.55mm) |
|
|
741X1635600FPRES ARRAY 8 RES 560 OHM 1506 |
3,180 |
|
Datasheet |
741 | 1506, Convex, Long Side Terminals | Tape & Reel (TR) | Active | Isolated | 560 | ±1% | 8 | - | - | 16 | 63mW | ±200ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | DDR SDRAM, DRAM, MDDR | Surface Mount | - | 0.156" L x 0.063" W (3.95mm x 1.60mm) | 0.022" (0.55mm) |
|
|
741X1635602FPRES ARRAY 8 RES 56K OHM 1506 |
4,818 |
|
Datasheet |
741 | 1506, Convex, Long Side Terminals | Tape & Reel (TR) | Active | Isolated | 56k | ±1% | 8 | - | - | 16 | 63mW | ±200ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | DDR SDRAM, DRAM, MDDR | Surface Mount | - | 0.156" L x 0.063" W (3.95mm x 1.60mm) | 0.022" (0.55mm) |
|
|
741X16356R0FPRES ARRAY 8 RES 56 OHM 1506 |
1,552 |
|
Datasheet |
741 | 1506, Convex, Long Side Terminals | Tape & Reel (TR) | Active | Isolated | 56 | ±1% | 8 | - | - | 16 | 63mW | ±200ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | DDR SDRAM, DRAM, MDDR | Surface Mount | - | 0.156" L x 0.063" W (3.95mm x 1.60mm) | 0.022" (0.55mm) |
|
|
741X16356R2FPRES ARRAY 8 RES 56.2 OHM 1506 |
4,306 |
|
Datasheet |
741 | 1506, Convex, Long Side Terminals | Tape & Reel (TR) | Active | Isolated | 56.2 | ±1% | 8 | - | - | 16 | 63mW | ±200ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | DDR SDRAM, DRAM, MDDR | Surface Mount | - | 0.156" L x 0.063" W (3.95mm x 1.60mm) | 0.022" (0.55mm) |
|
4610X-101-394LFRES ARRAY 9 RES 390K OHM 10SIP |
3,876 |
|
Datasheet |
4600X | 10-SIP | Bulk | Active | Bussed | 390k | ±2% | 9 | - | - | 10 | 200mW | ±100ppm/°C | -55°C ~ 125°C | - | - | - | Through Hole | 10-SIP | 0.998" L x 0.098" W (25.35mm x 2.49mm) | 0.200" (5.08mm) |
|
|
4610X-102-124LFRES ARRAY 5 RES 120K OHM 10SIP |
1,461 |
|
Datasheet |
4600X | 10-SIP | Bulk | Active | Isolated | 120k | ±2% | 5 | - | - | 10 | 300mW | ±100ppm/°C | -55°C ~ 125°C | - | - | - | Through Hole | 10-SIP | 0.998" L x 0.098" W (25.35mm x 2.49mm) | 0.200" (5.08mm) |
