Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
5500R-686JFIXED IND 68MH 140MA 52.8OHM SMD |
4,694 |
|
Datasheet |
5500R | 2-SMD | Tape & Reel (TR) | Active | - | Ferrite | 68 mH | ±5% | 140 mA | 70mA | Unshielded | 52.8Ohm Max | - | - | - | -55°C ~ 130°C | 1 kHz | - | Surface Mount | - | 1.080" L x 0.510" W (27.44mm x 12.96mm) | 0.520" (13.21mm) |
|
|
5500R-825JFIXED IND 8.2MH 390MA 6.44OHM SM |
2,131 |
|
Datasheet |
5500R | 2-SMD | Tape & Reel (TR) | Active | - | Ferrite | 8.2 mH | ±5% | 390 mA | 190mA | Unshielded | 6.44Ohm Max | - | - | - | -55°C ~ 130°C | 1 kHz | - | Surface Mount | - | 1.080" L x 0.510" W (27.44mm x 12.96mm) | 0.520" (13.21mm) |
|
|
5500R-826JFIXED IND 82MH 120MA 67.3OHM SMD |
3,574 |
|
Datasheet |
5500R | 2-SMD | Tape & Reel (TR) | Active | - | Ferrite | 82 mH | ±5% | 120 mA | 60mA | Unshielded | 67.3Ohm Max | - | - | - | -55°C ~ 130°C | 1 kHz | - | Surface Mount | - | 1.080" L x 0.510" W (27.44mm x 12.96mm) | 0.520" (13.21mm) |
|
750311826FIXED IND 1.6MH 150MA 1.5 OHM TH |
2,480 |
|
Datasheet |
- | Radial, Vertical (Open) | Tray | Active | Toroidal | - | 1.6 mH | ±20% | 150 mA | - | Unshielded | 1.5Ohm Max | - | - | - | - | 100 kHz | - | Through Hole | - | 0.580" Dia x 0.365" W (14.73mm x 9.27mm) | - |
|
CTH7F-222K2200UH AXIAL PWR LINE INDUCTOR |
2,752 |
|
Datasheet |
CTH7F | Axial | Tape & Reel (TR) | Active | - | - | 2.2 mH | ±10% | 160 mA | 270mA | Unshielded | 4.5Ohm Max | - | 650kHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.290" Dia x 0.602" L (7.37mm x 15.30mm) | - |
|
|
CTH7F-180K18UH AXIAL PWR LINE INDUCTOR |
4,673 |
|
Datasheet |
CTH7F | Axial | Tape & Reel (TR) | Active | - | - | 18 µH | ±10% | 1.3 A | 3A | Unshielded | 40mOhm Max | - | 11MHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.290" Dia x 0.602" L (7.37mm x 15.30mm) | - |
|
PL9221TFIXED IND 120UH 1.07A 316MOHM SM |
4,678 |
|
Datasheet |
PL92XX | Nonstandard | Tape & Reel (TR) | Active | - | - | 120 µH | ±20% | 1.07 A | 1.2A | Shielded | 316mOhm Max | - | - | - | -55°C ~ 130°C | - | - | Surface Mount | - | 0.413" L x 0.413" W (10.50mm x 10.50mm) | 0.201" (5.10mm) |
|
|
MILS1812-102KFIXED IND 1UH 755MA 350 MOHM SMD |
2,949 |
|
Datasheet |
MILS1812 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 1 µH | ±10% | 755 mA | - | Shielded | 350mOhm Max | 40 @ 7.9MHz | 160MHz | - | -55°C ~ 125°C | 7.9 MHz | - | Surface Mount | - | 0.189" L x 0.134" W (4.80mm x 3.40mm) | 0.134" (3.40mm) |
|
|
MILS1812-103KFIXED IND 10UH 333MA 1.8 OHM SMD |
3,714 |
|
Datasheet |
MILS1812 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 10 µH | ±10% | 333 mA | - | Shielded | 1.8Ohm Max | 50 @ 2.5MHz | 25MHz | - | -55°C ~ 125°C | 2.5 MHz | - | Surface Mount | - | 0.189" L x 0.134" W (4.80mm x 3.40mm) | 0.134" (3.40mm) |
|
|
MILS1812-104KFIXED IND 100UH 169MA 7 OHM SMD |
4,722 |
|
Datasheet |
MILS1812 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 100 µH | ±10% | 169 mA | - | Shielded | 7Ohm Max | 40 @ 790kHz | 7MHz | - | -55°C ~ 125°C | 790 kHz | - | Surface Mount | - | 0.189" L x 0.134" W (4.80mm x 3.40mm) | 0.134" (3.40mm) |
|
|
MILS1812-105KFIXED IND 1MH 60MA 55 OHM SMD |
3,468 |
|
Datasheet |
MILS1812 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 1 mH | ±10% | 60 mA | - | Shielded | 55Ohm Max | 40 @ 790kHz | 2MHz | - | -55°C ~ 125°C | 790 kHz | - | Surface Mount | - | 0.189" L x 0.134" W (4.80mm x 3.40mm) | 0.134" (3.40mm) |
|
|
MILS1812-122KFIXED IND 1.2UH 725MA 380MOHM SM |
2,175 |
|
Datasheet |
MILS1812 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 1.2 µH | ±10% | 725 mA | - | Shielded | 380mOhm Max | 40 @ 7.9MHz | 140MHz | - | -55°C ~ 125°C | 7.9 MHz | - | Surface Mount | - | 0.189" L x 0.134" W (4.80mm x 3.40mm) | 0.134" (3.40mm) |
|
|
MILS1812-123KFIXED IND 12UH 315MA 2 OHM SMD |
3,472 |
|
Datasheet |
MILS1812 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 12 µH | ±10% | 315 mA | - | Shielded | 2Ohm Max | 50 @ 2.5MHz | 22MHz | - | -55°C ~ 125°C | 2.5 MHz | - | Surface Mount | - | 0.189" L x 0.134" W (4.80mm x 3.40mm) | 0.134" (3.40mm) |
|
|
MILS1812-124KFIXED IND 120UH 163MA 7.5OHM SMD |
1,836 |
|
Datasheet |
MILS1812 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 120 µH | ±10% | 163 mA | - | Shielded | 7.5Ohm Max | 40 @ 790kHz | 6MHz | - | -55°C ~ 125°C | 790 kHz | - | Surface Mount | - | 0.189" L x 0.134" W (4.80mm x 3.40mm) | 0.134" (3.40mm) |
|
|
MILS1812-152KFIXED IND 1.5UH 706MA 400OHM SMD |
1,764 |
|
Datasheet |
MILS1812 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 1.5 µH | ±10% | 706 mA | - | Shielded | 222mOhm Max | 40 @ 7.9MHz | 110MHz | - | -55°C ~ 125°C | 7.9 MHz | - | Surface Mount | - | 0.189" L x 0.134" W (4.80mm x 3.40mm) | 0.134" (3.40mm) |
|
|
MILS1812-153KFIXED IND 15UH 301MA 2.2 OHM SMD |
2,313 |
|
Datasheet |
MILS1812 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 15 µH | ±10% | 301 mA | - | Shielded | 2.2Ohm Max | 50 @ 2.5MHz | 18MHz | - | -55°C ~ 125°C | 2.5 MHz | - | Surface Mount | - | 0.189" L x 0.134" W (4.80mm x 3.40mm) | 0.134" (3.40mm) |
|
|
MILS1812-154KFIXED IND 150UH 158MA 8 OHM SMD |
1,275 |
|
Datasheet |
MILS1812 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 150 µH | ±10% | 158 mA | - | Shielded | 8Ohm Max | 40 @ 790kHz | 5MHz | - | -55°C ~ 125°C | 790 kHz | - | Surface Mount | - | 0.189" L x 0.134" W (4.80mm x 3.40mm) | 0.134" (3.40mm) |
|
|
MILS1812-182KFIXED IND 1.8UH 681MA 430MOHM SM |
2,434 |
|
Datasheet |
MILS1812 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 1.8 µH | ±10% | 681 mA | - | Shielded | 430mOhm Max | 40 @ 7.9MHz | 100MHz | - | -55°C ~ 125°C | 7.9 MHz | - | Surface Mount | - | 0.189" L x 0.134" W (4.80mm x 3.40mm) | 0.134" (3.40mm) |
|
|
MILS1812-183KFIXED IND 18UH 288MA 2.4 OHM SMD |
3,345 |
|
Datasheet |
MILS1812 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 18 µH | ±10% | 288 mA | - | Shielded | 2.4Ohm Max | 50 @ 2.5MHz | 15MHz | - | -55°C ~ 125°C | 2.5 MHz | - | Surface Mount | - | 0.189" L x 0.134" W (4.80mm x 3.40mm) | 0.134" (3.40mm) |
|
|
MILS1812-184KFIXED IND 180UH 153MA 8.5OHM SMD |
4,423 |
|
Datasheet |
MILS1812 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 180 µH | ±10% | 153 mA | - | Shielded | 8.5Ohm Max | 40 @ 790kHz | 4.5MHz | - | -55°C ~ 125°C | 790 kHz | - | Surface Mount | - | 0.189" L x 0.134" W (4.80mm x 3.40mm) | 0.134" (3.40mm) |
