Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
0819R-84HFIXED IND 330UH 34MA 40.5 OHM TH |
3,033 |
|
Datasheet |
0819R | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 330 µH | ±3% | 34 mA | - | Unshielded | 40.5Ohm Max | 35 @ 790kHz | 6.2MHz | - | -55°C ~ 105°C | 790 kHz | - | Through Hole | - | 0.078" Dia x 0.200" L (1.98mm x 5.08mm) | - |
|
|
0819R-86HFIXED IND 390UH 33MA 43 OHM TH |
4,896 |
|
Datasheet |
0819R | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 390 µH | ±3% | 33 mA | - | Unshielded | 43Ohm Max | 35 @ 790kHz | 5.9MHz | - | -55°C ~ 105°C | 790 kHz | - | Through Hole | - | 0.078" Dia x 0.200" L (1.98mm x 5.08mm) | - |
|
|
0819R-88HFIXED IND 470UH 31.5MA 48 OHM TH |
2,380 |
|
Datasheet |
0819R | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 470 µH | ±3% | 31.5 mA | - | Unshielded | 48Ohm Max | 35 @ 790kHz | 5.4MHz | - | -55°C ~ 105°C | 790 kHz | - | Through Hole | - | 0.078" Dia x 0.200" L (1.98mm x 5.08mm) | - |
|
|
0819R-90HFIXED IND 560UH 28MA 60 OHM TH |
4,212 |
|
Datasheet |
0819R | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 560 µH | ±3% | 28 mA | - | Unshielded | 60Ohm Max | 35 @ 790kHz | 5MHz | - | -55°C ~ 105°C | 790 kHz | - | Through Hole | - | 0.078" Dia x 0.200" L (1.98mm x 5.08mm) | - |
|
|
0819R-92HFIXED IND 680UH 27MA 66 OHM TH |
4,923 |
|
Datasheet |
0819R | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 680 µH | ±3% | 27 mA | - | Unshielded | 66Ohm Max | 35 @ 790kHz | 4.5MHz | - | -55°C ~ 105°C | 790 kHz | - | Through Hole | - | 0.078" Dia x 0.200" L (1.98mm x 5.08mm) | - |
|
|
0819R-94HFIXED IND 820UH 25.5MA 72 OHM TH |
2,980 |
|
Datasheet |
0819R | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 820 µH | ±3% | 25.5 mA | - | Unshielded | 72Ohm Max | 35 @ 790kHz | 3.9MHz | - | -55°C ~ 105°C | 790 kHz | - | Through Hole | - | 0.078" Dia x 0.200" L (1.98mm x 5.08mm) | - |
|
|
0819R-96HFIXED IND 1MH 24.5MA 79 OHM TH |
3,130 |
|
Datasheet |
0819R | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 1 mH | ±3% | 24.5 mA | - | Unshielded | 79Ohm Max | 35 @ 790kHz | 3.3MHz | - | -55°C ~ 105°C | 790 kHz | - | Through Hole | - | 0.078" Dia x 0.200" L (1.98mm x 5.08mm) | - |
|
6727FIXED IND 35UH 2.5A 35 MOHM TH |
1,712 |
|
Datasheet |
6700 | Radial, Vertical, 4 Leads (Open) | Bulk | Obsolete | Toroidal | Iron Powder | 35 µH | ±15% | 2.5 A | - | Shielded | 35mOhm Max | - | - | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | - | 0.700" L x 0.425" W (17.78mm x 10.80mm) | 1.000" (25.40mm) |
|
|
6730FIXED IND 70UH 3A 50 MOHM TH |
2,169 |
|
Datasheet |
6700 | Radial, Vertical, 4 Leads (Open) | Bulk | Obsolete | Toroidal | Iron Powder | 70 µH | ±15% | 3 A | - | Shielded | 50mOhm Max | - | - | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | - | 0.850" L x 0.425" W (21.59mm x 10.80mm) | 1.000" (25.40mm) |
|
IHLP6767DZER2R2M11FIXED IND 2.2UH 26A 5.03MOHM SMD |
4,709 |
|
Datasheet |
IHLP-6767DZ-11 | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 2.2 µH | ±20% | 26 A | 17.5A | Shielded | 5.03mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.675" L x 0.675" W (17.15mm x 17.15mm) | 0.157" (4.00mm) |
|
ASPIAIG-Q1513-6R8M-TFIXED IND 6.8UH 27A 4.2MOHM SMD |
4,040 |
|
Datasheet |
ASPIAIG-Q1513 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 6.8 µH | ±20% | 27 A | 32A | Shielded | 4.2mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.689" L x 0.650" W (17.50mm x 16.50mm) | 0.512" (13.00mm) |
|
|
ASPIAIG-Q1513-8R2M-TFIXED IND 8.2UH 26A 5.7MOHM SMD |
1,072 |
|
Datasheet |
ASPIAIG-Q1513 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 8.2 µH | ±20% | 26 A | 29A | Shielded | 5.7mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.689" L x 0.650" W (17.50mm x 16.50mm) | 0.512" (13.00mm) |
|
|
ASPIAIG-Q1513-330M-TFIXED IND 33UH 14A 22.2MOHM SMD |
4,241 |
|
Datasheet |
ASPIAIG-Q1513 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 33 µH | ±20% | 14 A | 16A | Shielded | 22.2mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.689" L x 0.650" W (17.50mm x 16.50mm) | 0.512" (13.00mm) |
|
|
ASPIAIG-Q1513-220M-TFIXED IND 22UH 17A 13.86MOHM SMD |
4,989 |
|
Datasheet |
ASPIAIG-Q1513 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 22 µH | ±20% | 17 A | 19A | Shielded | 13.86mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.689" L x 0.650" W (17.50mm x 16.50mm) | 0.512" (13.00mm) |
|
|
ASPIAIG-Q1513-5R6M-TFIXED IND 5.6UH 29A 3.9MOHM SMD |
3,223 |
|
Datasheet |
ASPIAIG-Q1513 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 5.6 µH | ±20% | 29 A | 35A | Shielded | 3.9mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.689" L x 0.650" W (17.50mm x 16.50mm) | 0.512" (13.00mm) |
|
|
ASPIAIG-Q1513-150M-TFIXED IND 15UH 22A 7.5 MOHM SMD |
4,150 |
|
Datasheet |
ASPIAIG-Q1513 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 15 µH | ±20% | 22 A | 21A | Shielded | 7.5mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.689" L x 0.650" W (17.50mm x 16.50mm) | 0.512" (13.00mm) |
|
SWS-4.3-10FIXED IND 10UH 4.3A 26 MOHM SMD |
2,080 |
|
Datasheet |
SW | Nonstandard | Tape & Reel (TR) | Obsolete | Toroidal | Iron Powder | 10 µH | ±20% | 4.3 A | - | Unshielded | 26mOhm | - | - | - | -40°C ~ 130°C | 10 kHz | - | Surface Mount | - | 0.591" L x 0.591" W (15.00mm x 15.00mm) | 0.325" (8.25mm) |
|
|
SH260S-4.3-10FIXED IND 10UH 4.3A 26 MOHM SMD |
4,949 |
|
Datasheet |
SH260 | Nonstandard | Tape & Reel (TR) | Active | Toroidal | Iron Powder | 10 µH | ±20% | 4.3 A | - | Unshielded | 26mOhm | - | - | - | -40°C ~ 125°C | 10 kHz | - | Surface Mount | - | 0.614" L x 0.591" W (15.60mm x 15.00mm) | 0.404" (10.25mm) |
|
IHTH0750IZEB100M5AFIXED IND 10UH 17.7A 7.7 MOHM TH |
1,507 |
|
Datasheet |
IHTH-0750IZ-5A | Radial, Vertical Cylinder | Bulk | Active | - | Metal Composite | 10 µH | ±20% | 17.7 A | 13A | Shielded | 7.7mOhm Max | - | 9.77MHz | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Through Hole | - | 0.755" Dia (19.18mm) | 0.354" (8.99mm) |
|
|
IHTH0750IZEB2R2M5AFIXED IND 2.2UH 45A 1.63 MOHM TH |
3,687 |
|
Datasheet |
IHTH-0750IZ-5A | Radial, Vertical Cylinder | Bulk | Active | - | Metal Composite | 2.2 µH | ±20% | 45 A | 38A | Shielded | 1.63mOhm Max | - | 17.85MHz | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Through Hole | - | 0.755" Dia (19.18mm) | 0.354" (8.99mm) |
