Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CTCDRH6D28F-5R0N5.0UH SMD SHIELDED POWR INDUCTOR |
1,543 |
|
Datasheet |
CTCDRH6D28F | Nonstandard | Tape & Reel (TR) | Active | - | - | 5 µH | ±30% | - | 2.4A | Shielded | 31mOhm Max | - | - | - | -40°C ~ 80°C | 10 kHz | - | Surface Mount | - | 0.264" L x 0.264" W (6.70mm x 6.70mm) | 0.118" (3.00mm) |
|
|
CTCDRH6D28F-3R0N3.0UH SMD SHIELDED POWR INDUCTOR |
1,514 |
|
Datasheet |
CTCDRH6D28F | Nonstandard | Tape & Reel (TR) | Active | - | - | 3 µH | ±30% | - | 3A | Shielded | 24mOhm Max | - | - | - | -40°C ~ 80°C | 10 kHz | - | Surface Mount | - | 0.264" L x 0.264" W (6.70mm x 6.70mm) | 0.118" (3.00mm) |
|
|
CTCDRH6D28F-6R0N6.0UH SMD SHIELDED POWR INDUCTOR |
1,500 |
|
Datasheet |
CTCDRH6D28F | Nonstandard | Tape & Reel (TR) | Active | - | - | 6 µH | ±30% | - | 2.25A | Shielded | 35mOhm Max | - | - | - | -40°C ~ 80°C | 10 kHz | - | Surface Mount | - | 0.264" L x 0.264" W (6.70mm x 6.70mm) | 0.118" (3.00mm) |
|
|
CTCDRH6D28F-560N56UH SMD SHIELDED POWR INDUCTOR |
1,500 |
|
Datasheet |
CTCDRH6D28F | Nonstandard | Tape & Reel (TR) | Active | - | - | 56 µH | ±30% | - | 730mA | Shielded | 277mOhm Max | - | - | - | -40°C ~ 80°C | 10 kHz | - | Surface Mount | - | 0.264" L x 0.264" W (6.70mm x 6.70mm) | 0.118" (3.00mm) |
|
|
CTCDRH6D28F-270N27UH SMD SHIELDED POWR INDUCTOR |
1,500 |
|
Datasheet |
CTCDRH6D28F | Nonstandard | Tape & Reel (TR) | Active | - | - | 27 µH | ±30% | - | 1.05A | Shielded | 142mOhm Max | - | - | - | -40°C ~ 80°C | 10 kHz | - | Surface Mount | - | 0.264" L x 0.264" W (6.70mm x 6.70mm) | 0.118" (3.00mm) |
|
|
CTCDRH6D28F-180N18UH SMD SHIELDED POWR INDUCTOR |
1,020 |
|
Datasheet |
CTCDRH6D28F | Nonstandard | Tape & Reel (TR) | Active | - | - | 18 µH | ±30% | - | 1.32A | Shielded | 95mOhm Max | - | - | - | -40°C ~ 80°C | 10 kHz | - | Surface Mount | - | 0.264" L x 0.264" W (6.70mm x 6.70mm) | 0.118" (3.00mm) |
|
|
CTCDRH6D28F-220N22UH SMD SHIELDED POWR INDUCTOR |
445 |
|
Datasheet |
CTCDRH6D28F | Nonstandard | Tape & Reel (TR) | Active | - | - | 22 µH | ±30% | - | 1.2A | Shielded | 128mOhm Max | - | - | - | -40°C ~ 80°C | 10 kHz | - | Surface Mount | - | 0.264" L x 0.264" W (6.70mm x 6.70mm) | 0.118" (3.00mm) |
|
1008LS-682XJRC1008LS-682XJRC |
20,946 |
|
Datasheet |
1008LS | 1008 (2520 Metric) | Strip | Active | Wirewound | Ceramic, Ferrite | 6.8 µH | ±5% | 360 mA | - | Unshielded | 2Ohm Max | 37 @ 7.9MHz | 70MHz | AEC-Q200 | -40°C ~ 100°C | 7.9 MHz | - | Surface Mount | 1008 | 0.115" L x 0.110" W (2.92mm x 2.79mm) | 0.080" (2.03mm) |
|
|
1008LS-152XJRC1008LS-152XJRC |
10,951 |
|
Datasheet |
1008LS | 1008 (2520 Metric) | Strip | Active | Wirewound | Ceramic, Ferrite | 1.5 µH | ±5% | 630 mA | - | Unshielded | 760mOhm Max | 37 @ 50MHz | 190MHz | AEC-Q200 | -40°C ~ 100°C | 7.9 MHz | - | Surface Mount | 1008 | 0.115" L x 0.110" W (2.92mm x 2.79mm) | 0.080" (2.03mm) |
|
LPS4012-223MRCFIXED IND 22UH 700MA 600MOHM SM |
7,212 |
|
Datasheet |
LPS4012 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 22 µH | ±20% | 700 mA | 790mA | Shielded | 600mOhm Max | - | 25MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.154" L x 0.154" W (3.90mm x 3.90mm) | 0.047" (1.20mm) |
|
|
LPS4012-684MRCFIXED IND 680UH 135MA 13.5OHM SM |
3,782 |
|
Datasheet |
LPS4012 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 680 µH | ±20% | 135 mA | 110mA | Shielded | 13.5Ohm Max | - | 3MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.154" L x 0.154" W (3.90mm x 3.90mm) | 0.047" (1.20mm) |
|
|
LPS4012-682MRCFIXED IND 6.8UH 980MA 340MOHM SM |
2,662 |
|
Datasheet |
LPS4012 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 6.8 µH | ±20% | 980 mA | 1.4A | Shielded | 340mOhm Max | - | 55MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.154" L x 0.154" W (3.90mm x 3.90mm) | 0.047" (1.20mm) |
|
|
LPS4012-474MRCFIXED IND 470UH 175MA 10OHM SM |
2,063 |
|
Datasheet |
LPS4012 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 470 µH | ±20% | 175 mA | 120mA | Shielded | 10Ohm Max | - | 4MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.154" L x 0.154" W (3.90mm x 3.90mm) | 0.047" (1.20mm) |
|
|
LPS4012-184MRCFIXED IND 180UH 290MA 5OHM SM |
1,274 |
|
Datasheet |
LPS4012 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 180 µH | ±20% | 290 mA | 200mA | Shielded | 5Ohm Max | - | 8MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.154" L x 0.154" W (3.90mm x 3.90mm) | 0.047" (1.20mm) |
|
|
LPS4012-564MRCFIXED IND 560UH 140MA 12.5OHM SM |
1,222 |
|
Datasheet |
LPS4012 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 560 µH | ±20% | 140 mA | 115mA | Shielded | 12.5Ohm Max | - | 3.5MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.154" L x 0.154" W (3.90mm x 3.90mm) | 0.047" (1.20mm) |
|
|
LPS4012-681NRCFIXED IND 680NH 2.4A 55MOHM SM |
1,178 |
|
Datasheet |
LPS4012 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 680 nH | ±30% | 2.4 A | 3.7A | Shielded | 55mOhm Max | - | 220MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.154" L x 0.154" W (3.90mm x 3.90mm) | 0.047" (1.20mm) |
|
|
LPS4012-154MRCFIXED IND 150UH 320MA 3.5OHM SM |
640 |
|
Datasheet |
LPS4012 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | 150 µH | ±20% | 320 mA | 230mA | Shielded | 3.5Ohm Max | - | 10MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.154" L x 0.154" W (3.90mm x 3.90mm) | 0.047" (1.20mm) |
|
|
XFHCL38-R47MFIXED IND 0.47UH 9A 23 MOHM SMD |
3,000 |
|
Datasheet |
XFHCL38 | - | Tape & Reel (TR) | Obsolete | Molded | - | 0.47 µH | ±20% | - | - | Shielded | 23mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.142" L x 0.126" W (3.60mm x 3.20mm) | 0.079" (2.00mm) |
|
|
XFHCL38-1R0MFIXED IND 1.0UH 5A 38 MOHM SMD |
3,000 |
|
Datasheet |
XFHCL38 | - | Tape & Reel (TR) | Obsolete | Molded | - | 1 µH | ±20% | - | - | Shielded | 38mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.142" L x 0.126" W (3.60mm x 3.20mm) | 0.079" (2.00mm) |
|
|
DO1608C-224MLCFIXED IND 220UH 310MA 3.11OHM SM |
7,912 |
|
Datasheet |
DO1608C | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Ferrite | 220 µH | ±20% | 310 mA | 220mA | Unshielded | 3.11Ohm Max | - | 5.5MHz | AEC-Q200 | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.260" L x 0.175" W (6.60mm x 4.45mm) | 0.115" (2.92mm) |
